- Item Type:
- Ceiling Lights
- Light Source:
- LED
- Install Style:
- Surface Mounted
- Input Voltage(V):
- 120-277V
- Lamp Luminous Flux(lm):
- 4680LM
- CRI (Ra>):
- 80
- Working Temperature(℃):
- -20 - 45
- Working Lifetime(Hour):
- 50000
- Lamp Body Material:
- Iron
- IP Rating:
- IP20
- Certification:
- CE, ETL, REACH
- Place of Origin:
- Guangdong, China
- Brand Name:
- OEM
- Model Number:
- HG-L206
- Application:
- Theme Park
- Base Material:
- Steel
- Cover Material:
- Acrylic
- Material:
- iron+PC
- light source:
- SMD 2835
- power:
- 24W/40W/63W/85W
- size:
- 4FT/8FT
- Certificate:
- ETL/DLC
- Voltage:
- 120-277V
- CCT:
- 3000K-6000K
- Dimmable:
- 0-10V
- diffuser:
- milk prismatic acrylic
- emergency kit light:
- Led Strip Batten
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 122X20X11 cm
- Single gross weight:
- 4.0 kg
- Package Type:
- led linear fixture batten
- Picture Example:
- Lead Time:
Quantity(Piece) 1 - 1 2 - 100 101 - 500 >500 Est. Time(days) 5 15 14 To be negotiated
LED linear batten light
CONSTRUCTION
*Die formed of 0.5mm cold-rolled steel body
*All steel surface are painted after fabrication with high gloss backed white matte powder painted.
*High reflectance backed white acrylic paint finished
*High-diffusion light-milky PC diffuser
PRODUCT DISCRIPTION
* ETL & DLC listed; With LM79 & LM80;
* High luminous efficacy 110 lm/w or 130lm/w;
* 50,000 hours warranty 0-10V UL/CUL listed LED Driver, Flicking free.
* PF>0.90
* driver efficiency>87%;THD<20%;
* Installation: Surface mounted or Suspended
* Suitable for dry/damp location
* Designed for office, conference room etc.
* CCT: 3000K-6000K
* Lifetime: 5 years
Model No | A | B | C | WATTAGE | Efficiency |
HG-L206-XXX | 618mm | 115mm | 90mm | 18W | 110lm/w |
HG-L206/DM-XEE | 1206mm | 115mm | 90mm | 24W | 110lm/w |
HG-L206/DM-XE | 1206mm | 115mm | 90mm | 40W | 110lm/w |
HG-L206/DM-XY | 2438mm | 115mm | 90mm | 63W | 110lm/w |
HG-L206/DM-XXE | 2438mm | 115mm | 90mm | 85W | 110lm/w |
HG-L206/DM-XE-2 | 1206mm | 115mm | 90mm | 36W | 130lm/w |
HG-L206/DM-XY-2 | 2438mm | 115mm | 90mm | 63W | 130lm/w |
HG-L206/DM-XXE-2 | 2438mm | 115mm | 90mm | 85W | 130lm/w |
OPTIONS:
1-Available for dimmable version
2-Available for emergency version
3-Available for installing with sensor
TECHNICAL DATA
Item Number | HG-L206-XXX | HG-L206/DM-XEE | HG-L206/DM-XE | HG-L206/DM-XY | HG-L206/DM-XXE | HG-L206/DM-XE-2 | HG-L206/DM-XY-2 | HG-L206/DM-XXE-2 |
Total Input Watt | 18W | 24W | 40W | 63W | 85W | 36W | 63W | 85W |
Size | 2FT | 4FT | 4FT | 8FT | 8FT | 4FT | 8FT | 8FT |
Calculated L70 | 50,000 hrs | |||||||
Delivered Lumens | 1980LM | 2640LM | 4400LM | 6930LM | 9350LM | 4680LM | 8190LM | 11050LM |
Luminaire Efficacy Rating | 110LM/W | 130LM/W | ||||||
Correlated Color Temperature | 3000K-5500K | |||||||
Color Rendering Index | >80 |
PACKAGE/WEIGHT
Model No | Size | Master Carton Size | Qty/Carton | Weight |
|
| (LxWxH) |
| (KG)/(LBS) |
HG-L206-X | 2FT | 25.20"x10.63"X9.06" | 4 | 7.40KG/16.31lbs |
HG-L206-XEE | 4FT | 49.21"X10.63"X9.06" | 4 | 14.30KG/31.53lbs |
HG-L206-XE | 4FT | 49.21"X10.63"X9.06" | 4 | 14.30KG/31.53lbs |
HG-L206-XY | 8FT | 97.64"X10.63"X9.06" | 4 | 26.30KKG/57.98lbs |
HG-L206-XXE | 8FT | 97.60"X9.00"X9.45" | 4 | 26.30KKG/57.98lbs |
HG-L206-XE-2 | 4FT | 49.21"X10.63"X9.06" | 4 | 14.30KG/31.53lbs |
HG-L206-XY-2 | 8FT | 97.64"X10.63"X9.06" | 4 | 26.30KKG/57.98lbs |
HG-L206-XXE-2 | 8FT | 97.64"X10.63"X9.06" | 4 | 26.30KKG/57.98lbs |
Trade Terms: FOB Zhongshan
Shipping:By sea/by air/by DHL,Fedex,UPS and so on
Ports: Zhongshan, Shenzhen, Yantian, Shekou, Guangzhou
Payment terms:T/T /L/C at sight
Sample: availiable
Production capacity:3000pcs/day
MOQ:100PCS
Sampe lead time:7-10 working days after receipt of payment
Delevery time:30-35 working days after receipt of deposit
Packing:Export carton with foam
Remarks:
1. Halcon’s business principle: honesty, efficiency, sincerity
2. Advantage: designer with over 5 years’ experience + strict control on quality +
direct factory price + excellenct commnication group
Email: sales02@halconlighting.com
Q1. Can I have a sample order ?
A: Yes, we welcome sample order for led light to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time for led batten ?
A:The lead time of sample is 05-07 days,
Q3. Do you have any MOQ limit for led batten light order?
A: Low MOQ, 1 pc sample checking is welcome.
Q4. How do you ship the goods and how long does it take to arrive?
A: Airline and sea shipping
Q5. How to proceed an order for light?
A: Firstly let us know your requirements or application for light.
Secondly We quote according to your requirements or our suggestions for light.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production for led light.
