1. Reliable Performance:
Reliable Performance is the major advantage of Hi-earns products, and this reliability is based on the outstanding design in every aspect and strict Q.C. System.
2. Customer First:
We devote ourselves to develop products to meet customers" requirements .Our engineer develop and design new products for customers.
3. Strict test process before ex-factory:
Every product will be tested twice before ex-factory,and our products are 100% ex factory pass rate.
4. Low fuel consumption, easy maintenance
5. Certification: CE,ISO,GS,SONCAP etc.
6.Our logo or OEM
| Voltage | Frequency (HZ) | Phase | P.F(COS) | Standby Amps(A) | Standby Ratings (KW/KVA) | Prime Ratings(KW/KVA) |
| 440/254 | 50 | 3 | 0.8 | 52 | 32/40 | 30/38 |
| 415/240 | 50 | 3 | 0.8 | 56 | 32/40 | 30/38 |
| 400/230 | 50 | 3 | 0.8 | 58 | 32/40 | 30/38 |
| 380/220 | 50 | 3 | 0.8 | 61 | 32/40 | 30/38 |
| Standby Power Rating(ESP):The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption.No overload,utility parallel or negotiated outage operation capability is available at this rating. | ||||||
| Prime Power(PRP):Prime power is available for an unlimited number of annual hours in variable load application,in accordance with GB/T2820-97 (eqv ISO8528);A 10% overload capability is available for a period of 1 hour within a 12-hour period of operation. | ||||||
| ENGINE DATA | ||||||
| Engine Type | Yuchai Engine YC4FA55Z-D20 | |||||
| Shape | Straight 4 cylinder | |||||
| Bore×Stroke(mm) | 96×103 | |||||
| Power/Speed(KW/r/min) | 36.8 / 1500 | |||||
| Intake Type | Pressurize | |||||
| Adjust Speed Type | Electronic Speed Controller | |||||
| Engine output end specification--Flywheel case | SAE3# | |||||
| Dimension(mm) | 960×620×890 | |||||
| Weight(kgs) | 370 | |||||
| Alternator Data | ||||||
| Power Factor | 0.8 | |||||
| Insulation Class | H | |||||
| Lubricating System | Pressure,Split,Complex | |||||
| exhaust Air Temperature(℃) | ≤540 | |||||
| Altitude | ≤1000m | |||||
| Environment Temperature(℃) | 40 | |||||
| Connecting Type | 3 Phase and 4 Wires,"Y" type connecting | |||||
| Ignite sequence | 1-3-4-2 | |||||
| Intake Type | pressurize | |||||
| Rated Speed Regulation% | ≤±1% | |||||
| Phase | 3 | |||||
| Dimension & Weight | ||||||
| Open Type | Soundproof Type | |||||
| Overall Size:1.98(m)×0.84(m)×1.06(m) | Overall Size:2.1(m)×0.85(m)×1.24(m) | |||||
| Weight:746kg | Weight:806kg | |||||
