Smartgen water cooled 30hp generator
Click on the image to view the original image
Product: views:3Smartgen water cooled 30hp generator
Branch: Hi-earns or OEM
Unit Price: Negotiated
Min.Order:
Supply:
Delivery: Shipment within days since the date of payment
Valid until: Long Term
Updated on: 2019-12-03 18:33
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
Hi-earns or OEM
Model Number:
GF2-12KVA
Rated Power:
10KW
Output Type:
AC Three Phase
Rated Voltage:
220/380V
Rated Current:
19A
Speed:
1500/1800RPM
Frequency:
50/60HZ
color:
optional
name:
Smartgen water cooled 30hp generator
noise level:
soundproof silent one
digital panel and ATS:
optional
Alternator:
brushless
Certificate:
CE/ISO9001
Warranty:
1 Year
Controller:
Smartgen
Options:
Automatic Transfer Switch
Control panel:
Deepsea / ComAp / Harsen / Smartgen 6110
Supply Ability
Supply Ability:
40 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
iron frame or bubble paper with stretch film
Port
SHANGHAI or CIF destination port
Lead Time:
20 days after confirmed order

Smartgen water cooled 30hp generator

♦ Use good brand chinese engine, brushless alternator

♦ Canopy designed by ourselves

♦ We are factory, have low price spare parts and timely technical support



Model

GF2-12KVA

Standby power (50HZ)

11KW / 14KVA

Prime power (50HZ)

10KW / 12KVA

Voltage (V)

220/380V

Phase

3

Power factor (cosφ)

0.8

Standby amps (A)

21

Engine type

Quanchai Engine QC480D, 4-stroke, water-cooled, direct line

Rated RPM (r/min)

    1500rpm

Cooling system

Forced water-cooled

Fuel consumption (g/kw.h)

≤ 249

Rated speed regulation

≤ 5

Bore x stroke (mm)

80 x 90

Displacement (L)

1.809

Start Method

Electric start

Add oil capacity (L)

4L

Alternator Data

Power factor

0.8 Lag

Insulation class

H

Lubricating system

Pressure, split, complex

Exciter type

Brushless, self-exciting

Altitude

≤ 1000m

Environment temperature (°C)

40

Connecting type

3 phase and 4 wires, "Y" type connecting

Protection grade

IP23

Intake type

Natually-Aspirated

Rated speed regulation %

≤±1%

Phase

3

Overall size (m)

1.65 x 0.85 x 1.02(m)

Weight (kg)

600kg



♦  We are manufactory covering diesel and gasoline engine, diesel generator from 2-1000KW, water pump, trash pump, construction machinery like vibrator, rammer, compactor, concrete cutter, power trowel, farm machinery and so on

♦  Use famous brand spare parts

♦  ISO, CE, GS approved supplier

♦  One year warranty, complete spare parts for after-sales services

♦  Low price with good quality, reliable performance

♦  Easy to start and operate, convenient to move

♦  Low fuel consumption, easy maintenance

♦  Our logo or OEM



Advantages

 Economic and practical products from hi-earns, reliable performance.

 Choose hi-earns, choose a rest assured.

 Advanced production lines and test rooms.

 Complete system of IQC.

 Perfect QCP.

IQC

 Strict spare parts IQC system, to ensure every spare parts are qualified.

♦ Technical support in every step to eliminate all detailed questions.







Company&certificates

 Modern office building, we warmly welcome your visiting.

 We attend exhibitions domestic and overseas. Rich activities to improve work enthusiasm.

 ISO, CE, GS, Rohs certificates. We have been making good progress.


How to come to Hi-earns?
Line 1: TAXI
Shanghai International Airport(Pudong)
Cost(USD): 85
Time: 2.5 hours

Line 2: High speed rail
Shanghai HongQiao railway station---Changzhou railway station
Cost(USD): 20
Time: 1 hours



Our services

 With all the technical advantages, we promise customer one year warranty.

 Low price spare parts provided beyond warranty period.


HI-EARNS ALWAYS PROVIDE THE BEST, WE LISTEN TO YOUR NEEDS.


Any time you need us, we are here!
