EV80 diesel engine driven 10KW Changchai engine diesel generator

Click on the image to view the original image

Product：	views：5EV80 diesel engine driven 10KW Changchai engine diesel generator
Branch：	Hi-earns
Type：	open frame
Size：	112X76X82 cm
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-12-03 18:33

Product Details

Overview

Quick Details

Place of Origin:: Jiangsu, China

Brand Name:: Hi-earns

Model Number:: GF1-15000E

Rated Power:: 9KW/10KW

Output Type:: AC Three Phase

Rated Voltage:: 220,230,220/380,230/400

Rated Current:: 18A

Speed:: 3000/3600rpm

Frequency:: 50HZ/60HZ

Max. Power:: 10KW/12KVA

color:: optional

Type:: open frame

Engine:: Changchai EV80

Alternator:: 100% copper wire

Certificate:: CE/ISO9001

Warranty:: 1 Year

Control panel:: Smartgen digital panel

Packaging & Delivery

Selling Units:: Single item

Single package size:: 112X76X82 cm

Single gross weight:: 225.0 kg

Package Type:: Carton packing with plywood pallet

Lead Time:

Quantity(Piece)	1 - 5	6 - 30	>30
Est. Time(days)	20	25	To be negotiated

EV80 diesel engine driven 10KW Changchai engine diesel generator

*Changchai EV80 water-cooled diesel engine two-cylinder~
*100% copper wire alternator~
*Portable model open frame with wheels~
*9KW rated output~
*Four wheels ensure easy moving~
*Electric start with 45AH battery~

Simon Yang (Just press Chat Now!)

♦ Mobile/WhatsApp: 008613775105526

♦ E-mail: server-wm1(at)hiearns.com

♦ SKYPE: ysdsimon

♦ TradeManager: cn200048131

♦ WeChat: SimonMrYang

♦ QQ: 568238531

9KW changchai EV80 engine portable water cooled diesel generator

♦GF1-15000SE model: With Changchai EV80 water cooled diesel engine and 100% copper wire alternator ensure a 9KW rated output, and 10KW max. output! diesel generator

♦Electric start with 45AH battery; portable frame with 4 wheels ensure easy moving; Best designed muffler; portable model for home use! diesel generator

♦Also have silent model GF2-15000SE, the noise maybe little bigger, and the price can have a discount!

♦For air-cooled models we can produce 2 to 10KW, also water cooled models we can do 8 to 500KW, so just inform me some details about what you need, I can give you best quotation asap.

Voltage	Frequency (HZ)	Phase	P.F	Standby Amps	Standby Ratings (KW/KVA)	Prime Ratings (KW/KVA)
220	50	1	0.8	36	9/11.5	8/10
220/380	50	3	0.8	12	9/11.5	8/10
ENGINE DATA
Engine Type:				EV80 Changchai Engine
Engine type				V shape,4-stroke water-cooled diesel engine
Cylinder number				2
Bore×Stroke (mm)				80×79
Rated power/speed (kW / r/min)				12/3000,14/3600
Max.torque/speed (N.m / r/min)				43/2100, 42/2500
Intake type				Natural aspiration
Dimension(L×W×H) (mm)				650×486×528
Net weight (kg)				58
Combustion System				Vortex type
ALTERNATOR DATA
Alternator Data
Power Factor				0.8 Lag
Alternator Type				Brush Type
