Overview
Quick Details
- Place of Origin:
- Jiangsu, China
- Brand Name:
- Hi-earns
- Model Number:
- DP20HCIE
- Structure:
- Piston Pump
- Usage:
- Water
- Application:
- Sewage treatment/Building system/Agricultural/Power station
- Power:
- Electric
- Fuel:
- Diesel
- Pressure:
- High Pressure
- Color:
- Red, yellow and so on
- Type:
- high pressure cast iron water pump
- Material:
- cast iron
- Design:
- New
- Noise:
- low
- Warranty:
- One Year
- Engine model:
- HR186FA
- Quality:
- Best
- Lifetime:
- Longer
- Price:
- More competitive
Supply Ability
- Supply Ability:
- 200 Set/Sets per Day
Packaging & Delivery
- Packaging Details
- Carton with plastic film
- Port
- Shanghai port
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 5 6 - 20 >20 Est. Time(days) 10 15 To be negotiated
Related Products
2 inch High Pressure Cast Iron Water Pump 186 diesel engine for Irrigation
| WATER PUMP | Model | DP20HCI | |
| Suction,discharge port diameter [mm(in)] | 50(2") | ||
| Cont.head(m) | 90 | ||
| Self-priming time(s/4m) | 30 | ||
| Max suction head(m) | 8 | ||
| Cont.capacity(m³/hr) | 35 | ||
| ENGINE | Engine model | HR186FA | |
| Speed(rpm) | 3600 | ||
| Fuel consumption(g/kw.h) | 295 | ||
| Type | Single-cylinder,vertical,4-stroke air-cooled diesel engine | ||
Displacement(cc) | 418 | ||
Bore*stroke(mm) | 86x72 | ||
Starting system | Recoil or Electric | ||
| Fuel tank capacity(L) | 5.5 | ||
| STANDARD FEATURES | Oil alert | yes | |
| Connector of infall,Connecto of outfall | yes | ||
| Filter | yes | ||
| Seal ring | yes | ||
| Hoop | yes | ||
| DIMENSIONS | Dimension(L× W× H)(mm) | 490×475×605 | |
| Net weight(kg) | 50 | ||
| 20FT | 132 | ||
