Overview
Quick Details
- Applicable Industries:
- Hotels, Manufacturing Plant, Farms, Restaurant, Home Use, Retail, Construction works , Energy & Mining
- Condition:
- New
- Stroke:
- 4 Stroke
- Cylinder:
- Single Cylinder
- Cold Style:
- Air-cooled
- Start:
- Recoil and electric start
- Place of Origin:
- Jiangsu, China
- Brand Name:
- Hi-earns
- Dimension(L*W*H):
- 520x490x570mm
- Weight:
- 40kg
- Certification:
- CE/GS/ISO9001
- Warranty:
- One year
- After-sales Service Provided:
- Engineers available to service machinery overseas
- Color Optional:
- Yellow/Green/White/Green/Red/Orange/Blue
- Air filter:
- Oil bath
- Noise:
- Low level
- Fuel tank:
- Best quality
- Fuel pump:
- Best quality
- Displacement:
- 418cc
- Starting system:
- Recoil
- Shaft types:
- Thread shaft
- Fuel tank capacity:
- 5.5L
- Engine model:
- HR186FA
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 52X49X57 cm
- Single gross weight:
- 40.0 kg
- Package Type:
- Carton with plastic film and plywood pallets
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 10 11 - 50 >50 Est. Time(days) 7 15 To be negotiated
Related Products
| Model | HR186FA | |
| Type | Single-cylinder,vertical,4-stroke air-cooled diesel engine | |
| Combustion System | Direct Injection | |
| Bore×Stroke (mm) | 86×72 | |
| Displacement capacity (cc) | 418 | |
| Speed rpm) | 3000 | 3600 |
| Max.output (kw) | 6.5 | 7.1 |
| Rated output (kw) | 5.9 | 6.5 |
| Fuel | o# or-10# light diesel oil | |
| Fuel oil tank volume (L) | 5.5 | |
| Lubricatiom oil volume (L) | 1.65 | |
| Fuel oil consumption rate(g/kw.h) | 280 | |
| Starting system | Electric | |
| PTO rotation direction | It is clockwise as viewing from the flywheel end | |
| Dimension (mm) | 520x490x570 | |
| Gross weight (kg) | 40 | |
Product Description
Field of Application
♦ Our products are widely used in various fields, such as generators,water pumps, rotavator,concrete cutter,plate compactor,high pressure washer
