Overview
Quick Details
- Place of Origin:
- Jiangsu, China
- Brand Name:
- Hi-earns
- Model Number:
- GF2-30KW new generation
- Rated Voltage:
- 220/380,230/400,240/415V
- Rated Current:
- 57A
- Speed:
- 1500rpm/1800rpm
- Frequency:
- 50hz/60hz
- Engine:
- Quanchai engine
- Alternator:
- Stamford Brushless Alternator
- Type:
- portable,convenient trailer
- Color:
- Opotional
- Canopy:
- Silent and electric
- Phase:
- Three
- Engine type:
- Four cylinder four stroke
- Price:
- Competitive price
- Quality:
- Better andbest
- Power factor:
- 0.8
Supply Ability
- Supply Ability:
- 100 Piece/Pieces per Day
Packaging & Delivery
- Packaging Details
- iron frame packingportable generator
- Port
- Shanghai or other Chinese port
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 1 2 - 4 >4 Est. Time(days) 25 35 To be negotiated
Related Products
Voltage | Frequency (HZ) | Phase | P.F(COS) | Standby Amps | Standby Ratings (KW/KVA) | Prime Ratings (KW/KVA) |
| 440/254 | 50 | 3 | 0.8 | 52 | 32/40 | 30/37.5 |
| 415/240 | 50 | 3 | 0.8 | 56 | 32/40 | 30/37.5 |
| 400/230 | 50 | 3 | 0.8 | 58 | 32/40 | 30/37.5 |
| 380/220 | 50 | 3 | 0.8 | 61 | 32/40 | 30/37.5 |
| ENGINE DATA | ||||||
| Engine Type | Quanchai Engine 4105D. Four stroke,Water-cooled, Direct line | |||||
| Rated RPM (r/min) | 1500rpm | |||||
| Cooling System | Forced Water-cooled | |||||
| Fuel Consumption (≤g/kw.h) | ≤238 | |||||
| Cylinder Number | 4 | |||||
| Bore×Stroke (mm) | 105×118 | |||||
| Displacement (L) | 4.087 | |||||
| Start Method | Electric Start | |||||
| Rated Speed Regulation(g/kW·h) | ≤5 | |||||
| Combustion Chamber Type | Direct Injection | |||||
| Add Oil Capacity | 8L | |||||
| ALTERNATOR DATA | ||||||
| Alternator Data | ||||||
| Power Factor | 0.8 Lag | |||||
| Insulation Class | H | |||||
| Exciter Type | Brushless,self-exciting | |||||
| Altitude | ≤1000m | |||||
| Phase | 3 | |||||
| Dimension & Weight | ||||||
| Open Type | Soundproof Type | |||||
| Overall Size :1.9(m)×0.88(m)×1.18(m) | Overall Size :2.12(m)×0.88(m)×1.30(m) | |||||
| Net Weight :650kg | Net Weight :800kg | |||||
