Overview
Quick Details
- Place of Origin:
- Jiangsu, China
- Brand Name:
- Hi-earns
- Model Number:
- DG6000E
- Rated Voltage:
- 220,230,240V
- Rated Current:
- 21A
- Speed:
- 3000RPM
- Frequency:
- 50HZ
- Color:
- Green/White/black/Red/Blue
- Rated voltage:
- 110/220/230/240 V
- Noise level at 7 meters:
- 80-85dB
- Diesel generator type:
- Air-cooled four stroke diesel generator
- Alternator brand:
- SENCI and KETE
- Engine:
- 186FA-10HP
- Certificate:
- ISO9001/CE
- Control panel:
- Common/digital /ATS
- Engine Brand:
- Hiearns
- Generator type:
- Open frame
Supply Ability
- Supply Ability:
- 500 Piece/Pieces per Day
Packaging & Delivery
- Packaging Details
- 1.Carton with plywood plate
2.One 20FT can load 102pcs, one 40FT can load 210pcs.
- Port
- Shanghai or other Chinese port
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 10 11 - 50 >50 Est. Time(days) 10 20 To be negotiated
Related Products
5KVA open type single phase single cylinder air-cooled diesel generator
| GENERATOR | Model | DG6000E | |
| Frequency(HZ) | 50 | 60 | |
| Max. output(kw) | 5.0 | 5.5 | |
| Rated output(kw) | 4.6 | 5.0 | |
| Rated. AC voltage(v) | 120, 220, 230, 240 | ||
| Power factor(cosΦ ) | cosΦ =1 | ||
| DC output (v) | 12V/8.3A | ||
| Phase | Single phase | ||
| Alternator type | self-excited | ||
| Starting system | Recoil or Electric | ||
| Operating noise level(at 7m) | 80~85 | ||
| Fuel tank capacity(L) | 12.5 | ||
| Continues work(hr) | 8.5 | 7.7 | |
| ENGINE | Model | HR186FA | |
| Engine type | Single-cylinder, vertical, 4-stroke air-cooled diesel engine | ||
| Bore× stroke(mm) | 86×72 | ||
| Fuel | 0# or -10# light diesel fuel | ||
| Lubrication oil volume(L) | 1.65 | ||
| Combustion system | Direct lnjection | ||
| STANDARD FEATURES | Voltmeter | yes | |
| AC Output Socket | 2 | ||
| AC circuit breaker | yes | ||
| Oil warning light | yes | ||
| Oil alert | yes | ||
| OPTIONAL FEATURES | DC circuit breaker | optional | |
| Calculagraph | optional | ||
| Big Wheel | optional | ||
| Three phase voltage | optional | ||
| Current meter | optional | ||
| ATS | optional | ||
| Remote control | optional | ||
| Welding | No | ||
| DIMENSIONS | Dimension(L× W× H)(mm) | 700×470×600 | |
| Net weight(kg) | 84 | ||
| 20FT | 102 | ||
Product Description
Field of Application
♦ Our products are widely used in various fields, such as construction site,supermarket,hotel,server room,hospital,animal husbandry,fishery,camping
Care & Maintenance
About Us
Exhibition
♦ We attend exhibitions domestic and overseas. Rich activities to improve work enthusiasm.
♦ ISO, CE Certificates. We have been making good progress.
Company Information
Our Services
Contact us
How to come to Hi-earns?
♦ Line 1:TAXI
Shanghai International Airport(Pudong)
Cost(USD):85
Time:2.5 hours
♦Line 2:High speed rail
Shanghai Hongqiao railway station---Changzhou railway station
Cost(USD):20
Time:1 hour
Lisa Jia
Sales manager
♦ Mobile/WhatsApp/Wechat: +86-13328198882
♦ E-mail: hiearns5@ vip.163.com
♦ SKYPE: jia.lisa7
♦ TradeManager: cn220086459
♦ QQ: 1562536125
