Click on the image to view the original image
Overview
Quick Details
- Place of Origin:
- Jiangsu, China
- Brand Name:
- Hi-earns
- Model Number:
- DG8000E3
- Rated Voltage:
- 220/380V
- Rated Current:
- 10A
- Speed:
- 3000rpm/3600rpm
- Frequency:
- 50HZ/60HZ
- Industrial Diesel generator:
- diesel generator set
- Color:
- Green/White/black/Red/Blue
- Rated voltage:
- 120,220,230,240,120/240,220/380,230/400,240/415
- Noise level at 7 meters:
- 80-85db
- Diesel generator type:
- Air-cooled four stroke diesel generator
- Engine Model:
- 192FB
- Certificate:
- ISO9001:2008CE
- Alternator:
- copper wire
- Warranty:
- 1 Year
- Options:
- Customer's Logo
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 76X50X64 cm
- Single gross weight:
- 125.0 kg
- Package Type:
- Carton with plywood plate
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 20 >20 Est. Time(days) 15 To be negotiated
Related Products
| Model | DG8000E3 | |
| Frequency (HZ) | 50HZ | 60HZ |
| Max.output (KW) | 6.5 | 7 |
| Rated output(KW) | 6 | 6.5 |
| Rated AC Voltage(V) | 110, 220, 230, 240, 110/220, 220/380, 230/400, 240/415 | |
| Power Factor | 1(single phase) / 0.8(three phase) | |
| DC output | 12V/8.3A | |
| Phase | Single Phase/three phase | |
| Alternator Type | Self-excited, 2-pole, Single/three phase alternator | |
| Starting System | Electric | |
| Noise Level (Dba/7m) | 80-85Dba | |
| Fuel Tank Capacity (L) | 12.5L | |
| Continues Running Time (hr) | 5.9 | 5.5 |
| Engine Model | HR192FB | |
| Engine Type | single-cylinder, vertical,4-stroke air-cooled diesel engine | |
| Bore×Stroke (mm) | 92×75 | |
| Displacement Capacity | 498cc | |
| Fuel Consumption rate | ≤280 | |
| Fuel | 0# or -10# light diesel fuel | |
| Lubrication oil Volume (L) | 1.65L | |
| Combustion System | Direct Injection | |
| Voltmeter | YES | |
| AC Output Socket | 2 | |
| AC Circuit Breaker | YES | |
| Oil warning Light | YES | |
| Oil Alert | YES | |
| Dimension (L×W×H)(mm) | 760×500×640 | |
| Net Weight (kgs) | 119 | |
| 20FT | 105 | |
