3KVA timer silent single phase diesel generator
♦ Use good brand spare parts, unique design canopy
♦ 100% copper alternator. Portable type, with four wheels and brake, easy to move
♦ We are factory, have low price spare parts and timely technical support
GENERATOR | Model | DG3500SE | ||
Frequency (HZ) | 50 | 60 | ||
Max. output (KW) | 3 | 3.3 | ||
Rated output (KW) | 2.8 | 3 | ||
Rated. AC voltage (V) | 120, 220, 230, 240 | |||
Power factor (cosΦ) | cosΦ=1 | |||
DC output (V) | 12V/8.3A | |||
Phase | Single phase | |||
Alternator type | self-excited, 2-pole, single phase alternator | |||
Starting system | Electric | |||
Operating noise level (at 7m) | 68~72 | |||
Fuel tank capacity (L) | 16 | |||
Continues work (H) | 13 | 11.8 | ||
ENGINE | Model | HR178F | ||
Engine type | Single-cylinder, vertical, 4-stroke air-cooled diesel engine | |||
Bore×stroke (mm) | 78×62 | |||
Fuel | 0# or -10# light diesel fuel | |||
Lubrication oil volume (L) | 1.65 | |||
Combustion system | Direct lnjection | |||
STANDARD FEATURES | Voltmeter | yes | ||
AC Output Socket | 2 | |||
AC circuit breaker | yes | |||
Oil warning light | yes | |||
Oil alert | yes | |||
OPTIONAL FEATURES | DC circuit breaker | optional | ||
Calculagraph | optional | |||
Big Wheel | optional | |||
Three phase voltage | optional | |||
Current meter | optional | |||
ATS | optional | |||
Remote control | optional | |||
Welding | optional | |||
DIMENSIONS | Dimension (L×W×H) (mm) | 850×560×760 | ||
Net weight (kg) | 135 | |||
20FT | 72 | |||
♦ We are manufactory covering diesel and gasoline engine, diesel generator from 2-1000KW, water pump, trash pump, construction machinery like vibrator, rammer, compactor,
concrete cutter, power trowel, farm machinery and so on
♦ ISO, CE, GS approved supplier
♦ One year warranty, complete spare parts for after-sales services
♦ Low price with good quality, reliable performance
♦ Easy to start and operate, convenient to move
♦ Low fuel consumption, easy maintenance
♦ Strict spare parts IQC system, to ensure every spare parts are qualified.
♦ Technical support in every step to eliminate all detailed questions.
♦ Modern workshops have advanced production lines and professional knowledge of assembly.
♦ Flow card to record each details carefully.
♦ Test engine at least twice before ex-factory.
♦ Strong packaging to ensure safty during transportation.
♦ 7 layer corrugated carton or wooden box packaging for products.
♦ Modern office building, we warmly welcome your visiting.
♦ We attend exhibitions domestic and overseas. Rich activities to improve work enthusiasm.
♦ ISO, CE, GS, Rohs certificates. We have been making good progress.
