25kva silent power generator price generator spare parts
♦ Use good brand chinese engine, brushless alternator
♦ Canopy designed by ourselves, silent
♦ We are factory, have low price spare parts and timely technical support.
Model | GF2-25KVA |
Standby power(50HZ) | 22KW/28KVA |
Prime power(50HZ) | 20KW/25KVA |
Voltage(V) | 220/380V |
Phase | 3 |
P.F(COSφ) | 0.8 |
Standby Amps(A) | 42 |
Engine type | DCEC Cummins 4B3.9-G2, 4-stroke |
Air intake system | Air natural |
Fuel system | A type fuel pump |
Fuel consumption(g/kw.h) | ≤ 214 |
Cylinder arrangement | 4 in line |
Displacement | 3.9L |
Bore x Stroke | 102 x120(mm) |
Compression Ratio | 16.5:1 |
Rated RPM | 1500rpm |
Max.Standby Power at Rated RPM | 27KW/36.7HP |
Governor Type | Electronic(optional) |
Max Water Temperature | 104 degree celsius |
Alternator Data | |
Number of Phase | 3 |
Connecting Type | 3 Phase and 4 Wires, "Y" type connecting |
Number of Bearing | 1 |
Power Factor | 0.8 Lag |
Protection Grade | IP23 |
Altitude | ≤ 1000m |
Exciter Type | Brushless, self-exciting |
Insulation Class,Temperature Rise | H/H |
Telephone Influence Factor(TIF) | <50 |
THF | <2% |
Voltage Regulation, Steady State | ≤±1% |
Alternator Capacity | 27.5KVA |
Alternator Efficiencies | 86.2% |
Air cooling Flow | 0.095m3/s |
Overall Size | 2.2x1.0x1.45(m) |
Weight | 1300kg |
♦ We are manufactory covering diesel and gasoline engine, diesel generator from 2-1000KW, water pump, trash pump, construction machinery like vibrator, rammer, compactor, concrete cutter, power trowel, farm machinery and so on ♦ Use famous brand spare parts
♦ ISO, CE, GS approved supplier
♦ One year warranty, complete spare parts for after-sales services
♦ Low price with good quality, reliable performance
♦ Easy to start and operate, convenient to move
♦ Low fuel consumption, easy maintenance
♦ Our logo or OEM
♦ Economic and practical products from hi-earns, reliable performance.
♦ Choose hi-earns, choose a rest assured.
♦ Advanced production lines and test rooms.
♦ Complete system of IQC.
♦ Perfect QCP.
♦ Strict spare parts IQC system, to ensure every spare parts are qualified.
♦ Technical support in every step to eliminate all detailed questions.
♦ Modern workshops have advanced production lines and professional knowledge of assembly.
♦ Flow card to record each details carefully.
♦ Test engine at least twice before ex-factory.
♦ Strong packaging to ensure safty during transportation.
♦ 7 layer corrugated carton or wooden box packaging for products.
♦ Modern office building, we warmly welcome your visiting.
♦ We attend exhibitions domestic and overseas. Rich activities to improve work enthusiasm.
♦ ISO, CE, GS, Rohs certificates. We have been making good progress.
♦ Line 1: TAXI
Shanghai International Airport(Pudong)
Cost(USD): 85
Time: 2.5 hours
Shanghai HongQiao railway station---Changzhou railway station
Cost(USD): 20
Time: 1 hours
♦ With all the technical advantages, we promise customer one year warranty.
♦ Low price spare parts provided beyond warranty period.
