16KW/20KVA water cooled diesel generation
Click on the image to view the original image
Product： views：316KW/20KVA water cooled diesel generation
Branch： hiearns
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-12-03 18:37
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
hiearns
Model Number:
GF2-16KW
Rated Power:
15KW
Output Type:
AC Three Phase
Rated Voltage:
220/380, 230/400V
Speed:
1500rpm/1800rpm
Frequency:
50/60HZ
color:
white
Supply Ability
Supply Ability:
100 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
iron frame or bubble paper with stretch film
Port
shanghai
Lead Time:
30days after reveiving the deposit

silent diesel generator set 16KW


Standby Power  16.2KW / 20KVA
Prime Power15KW / 19KVA
ModelQC490D
Cylinder Number4
Bore×Stroke(mm)90×105
Displacement(L)2.672
Rated RPM(r/min)1500
Rated Speed Regulation %≤5
Rated Fuel Consumption(g/kW·h)≤243
Cylinder Head TypeWet type
Diesel Generator TypeDirect line,Water-cooled,Four stroke
Intake TypeNatually-Aspirated
Combustion Chamber TypeDirect Injection
Lubricating SystemPressure,Split,Complex
Flywheel Cover SpecificationSAE4#
Flywheel SpecificationSAE7.5″
Exhaust Fan Diameter(mm)φ410
Flywheel Teeth Number120
Add Oil Capacity6.5L
Voltage (V)380/220
Frequency (HZ)50
Insulation ClassH
Rated Current (A)28
Phase3
Altitude≤1000m
Power Factor0.8
Voltage Regulation,Stead State≤±1%
Connecting Type3 Phase and 4 Wires,"Y" type connecting
AVRSX460
Environment Temperature (°c)40
Exciter TypeBrushless,self-exciting
Protection GradeIP23
Silent Type"s Dimension Length × Width × Height (mm)1950×850×1150
Silent Type"s Net Weight(Kg)706
Silent Type"s 20FT Loading Quantity12PCS







Advantages

♦ Economic and practical products from hi-earns,reliable performance.

♦ Choose hi-earns,choose a rest assured.

♦ Advanced production lines and test rooms.

♦ Complete system of IQC.

♦ Perfect QCP.





IQC

♦ Strict spare parts IQC system,to ensure every spare parts are qualified.

♦ Technical support in every step to eliminate all detailed questions.



















Our Services

♦ With all the technical advantages,we promise customer one year warranty.

♦ Low price spare parts provided beyond warranty period.
