| Model | DG11000SE | ||
| Generator | Frequency(HZ) | 50 | |
| Max.output (kw) | 7.2 | ||
| Rated output(kw) | 7 | ||
| Rated.AC voltage(V) | 220,230,220/380,230/400 | ||
| Power factor(cos) | 1 | ||
| DC output (V) | 12V/8.3A | ||
| Phase | Single phase | ||
| Alternator type | Self-excited,2-pole,Single phase alternator | ||
| Starting system | Electric | ||
| noise level(at 7m) | 68-72 | ||
| Fuel tank capacity(L) | 30 | ||
| Continuous work (hr) | 12 | ||
| Engine | Model | HR198FA | |
| Engine type | single-cylinder, vertical,4-stroke air-cooled diesel engine | ||
| Bore×stroke(mm) | 98×84 | ||
| Fuel | 0# or -10# light diesel oil | ||
| Lubrication oil volume(L) | 1.65 | ||
| Combustion system | Direct Injection | ||
Standard feature | Voltmeter | yes | |
| AC Output Socket | 2 | ||
| Ac circuit breaker | yes | ||
| Oil warning light | yes | ||
| Oil alert | yes | ||
| DC circuit breaker | yes | ||
| 36AH battery | yes | ||
Optional feature | Calculagraph | Optional | |
| Big wheel | Optional | ||
| Three phase voltage | Optional | ||
| Current meter | Optional | ||
| ATS | Optional | ||
| Digital Panel | Optional | ||
| Remote control | Optional | ||
| Welding | Optional | ||
| Dimension | Dimension(L×W×H)(mm) | 1100×760×860 | |
| Net weight(kg) | 230 | ||
| 20FT | 30 | ||
| 40FT | 96 | ||
♦ Economic and practical products from hi-earns,reliable performance.
♦ Choose hi-earns,choose a rest assured.
♦ Advanced production lines and test rooms.
♦ Complete system of IQC.
♦ Perfect QCP.
♦ Strict spare parts IQC system,to ensure every spare parts are qualified.
♦ Technical support in every step to eliminate all detailed questions.
♦ Modern workshops have advanced production lines and professional knowledge of assembly.
♦ Flow card to record each details carefully.
♦ Test engine at least twice before ex-factory.
♦ Strong packaging to ensure safty during transportation.
♦ 7 layer corrugated carton or wooden box packagine for products.
♦ We are manufactory covering diesel and gasoline engine,diesel generator from 2-1000KW,water pump,trash pump,construction machinery like vibrator,rammer,compactor,concrete cutter,power trowel,farm machinery,high pressure washer and so on.
♦ Modern office building,we warmly welcome your visiting.
♦ We attend exhibitions domestic and overseas.Rich activities to improve work enthusiasm.
♦ ISO,CE,GS,Rohs certificates.We have been making good progress.
How to come to Hi-earns?
♦ Line 1:TAXI
Shanghai International Airport(Pudong)
Cost(USD):85
Time:2.5 hours
♦Line 2:High speed rail
Shanghai Hongqiao railway station---Changzhou railway station
Cost(USD):20
Time:1 hour
♦ With all the technical advantages,we promise customer one year warranty.
♦ Low price spare parts provided beyond warranty period.
