Overview
Quick Details
- Place of Origin:
- Jiangsu, China
- Brand Name:
- Hi-earns
- Model Number:
- DG7000E
- Rated Voltage:
- 220,230,240
- Rated Current:
- 20.9
- Speed:
- 3000rpm/3600rpm
- Frequency:
- 50/60HZ
- type:
- open with beam
Supply Ability
- Supply Ability:
- 200 Piece/Pieces per Day
Packaging & Delivery
- Packaging Details
- carton
- Port
- FOB Shanghai or CIF destination port
- Lead Time:
Quantity(Pieces) 1 - 5 6 - 100 101 - 200 >200 Est. Time(days) 7 10 12 To be negotiated
Video Description
Related Products
5.5KW diesel generator three phase electric start
Model | DG8000(E) | ||
GENERATOR | Frequency (HZ) | 50 | 60 |
Max.output (KW) | 6.5 | 7 | |
Rated output (KW) | 6 | 6.5 | |
Rated AC voltage (V) | 120, 220, 230, 240, 220/380, 230/400, 240/415 | ||
Power factor | 1 | ||
DC output (V) | 12V/8.3A | ||
Phase | Single phase or Three phase | ||
Alternator type | Self-excited, 2-pole alternator | ||
Starting system | Manual or electric | ||
Noise level (Dba/7m) | 80-85 | ||
Fuel tank capacity (L) | 12.5 | ||
Continuous running time (hr) | 5.9 | 5.5 | |
ENGINE | Engine model | HR192FD | |
Engine type | Single-cylinder, vertical, 4-stroke air-cooled diesel engine | ||
Bore×Stroke (mm) | 92×75 | ||
Fuel consumption rate (g/kw.h) | ≤280 | ||
Fuel | 0# or -10# light diesel oil | ||
Lubrication oil volume (L) | 1.65 | ||
Combustion system | Direct Injection | ||
STANDARD FEATURES | Voltmeter | YES | |
AC output socket | 2 | ||
AC circuit breaker | YES | ||
Oil warning light | YES | ||
Oil alert | YES | ||
OPTIONAL FEATURES | DC circuit breaker | OPTIONAL | |
Calculagraph | OPTIONAL | ||
Big wheel | OPTIONAL | ||
Three phase voltage | OPTIONAL | ||
Current meter | OPTIONAL | ||
ATS | OPTIONAL | ||
Remote control | OPTIONAL | ||
DIMENSIONS | Packing dimention (LxWxH) (cm) | 71×50×64 | |
Gross weight (kgs) | (110)120 | ||
20FT loading pcs | 105 | ||
40HQ loading pcs | 227(208) |
Product Description
Field of Application
♦ Our products are widely used in various fields, such as construction site,supermarket,hotel,server room,hospital,animal husbandry,fishery,camping
Care & Maintenance
About Us
Exhibition
♦ We attend exhibitions domestic and overseas. Rich activities to improve work enthusiasm.
♦ ISO, CE Certificates. We have been making good progress.
Company Information
Our Services
