- Item Type:
- Ceiling Lights
- Light Source:
- LED
- Install Style:
- Surface Mounted
- Input Voltage(V):
- 85-265VAC
- Lamp Luminous Flux(lm):
- 1800
- CRI (Ra>):
- 80
- Working Temperature(℃):
- -40 - 60
- Working Lifetime(Hour):
- 50000
- Lamp Body Material:
- Aluminum
- IP Rating:
- IP65
- Certification:
- CE, EMC, LVD, RoHS, SAA
- Place of Origin:
- Guangdong, China
- Brand Name:
- hofoled
- Model Number:
- HF-CL20R300
- Application:
- HOTEL
- Base Material:
- Aluminum
- Cover Material:
- Plastic
- LED Light Source:
- SMD2835
- Warranty:
- 3 years
- Aluminum housing color:
- black,white,grey color
- power:
- 15w 20w 30w 40w available
- Product Size:
- 300*300*85mm
- IK Rating:
- IK10
- Material:
- Die-casting aluminum, milky PC cover
- Function:
- can add motion sensor/Detector/Dimmable
- Style:
- round,square led ceiling light
- Product name:
- led ceiling light, led bulkhead light,led bathroom light
- Supply Ability:
- 10000 Piece/Pieces per Month
- Packaging Details
- normally inner white box, color box is customized by customer
5 pcs/ Carton, 12 KG by dimension, G.W:10KG
- Port
- Shenzhen
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 200 >200 Est. Time(days) 7 To be negotiated
energy saving ce rohs approval Warm white nature white modern ceiling fan with led light
Same diameter 300mm for 20W 30W 40W, Black,White, Grey colors for choose
| Power Consumption | 20W | 30W | 40W |
| Luminous Flux | 1800Lm | 2700Lm | 3600Lm |
| Light Source | High Power SMD LED | ||
| CRI | 85 | ||
| Chip Type | SMD2835 | ||
| Driver Input Voltage | 85~265v AC 50 / 60Hz | ||
| Colour Temperature (CCT) | 2800K~3100K | 3800K~4250K | 6000K~6500K |
| Power Factor | 0.95 | ||
| Rated Life (L70) | 50,000Hrs | ||
| Working Temperature | -10C ~ 40C | ||
| Storage Temperature | -20C ~ 80C | ||
| Working Humidity | 5% ~ 95%RH | ||
| Lamp Housing | Aluminium Alloy | ||
| Lens | Poly Carbonate (PC) | ||
| Finish | Powder Coat Black | ||
| Dimensions | 300*300*85mm | ||
| Installation | Wall Mounted, Surface mounted | ||
| Installation | IP65 Waterproof | ||
| Additional | CE ROHS SAA IK10 Approved | ||
LED Ceiling Light Features:
1. Die-casting aluminum lamp body, excellent heat dissipation
2. IP65 waterproof, dustproof for indoor and outdoor lighting
3. Milky white PC cover, high impact resistance IK10 approval
4. Stainless steel hexagon socket head cap screws
5. Can built-in motion sensor, Emergency time 1-3 hours
6. Black / white / grey aluminum housing color available
7. EGlow wire test at 850 ℃ pass NF EN 60695-2-1, VDE approval.
LED Ceiling Light Photos:
Model:HF-CL20R300(20W), HF-CL30R300(30W),HF-CL40R300(40W)
Housing color: WHITE/BLACK/GREY
Function
1. Motion(microwave) Sensor Function: (only sensor)
Microwave Motion Sensor are available to add inside the led ceiling light, The Microwave Motion Sensor is an innovative motion sensor, switch on the light on detection of movement, and switch off after a hold time when there is no motion detected. As built-in daylight sensor can read brightness value, the sensor does not switch on the light if with sufficient natural light.
Detection area: from 2m to 10m
Hold time: 5s, 30s, 90s, 3min, 20min, 30min
Daylight sensor: 2LUX, 10LUX, 25LUX, 50LUX, Disable
2. Emergency function: (Emergency only or Emergency+Sensor)
Emergency power: 8 W
Emergency Time: 1Hour - 3 Hours
Lithium Battery Capacity
With main power AC85-265V, we offer 15W and 20W.
When power cut off, with emergency power 8W , running time: 1hours to 3 hours
Charge time: 10-16 Hours, when indicator of charger on red is charging,off means full charged.
Certification and Factory QC Process:
Ceiling LED Light Applications:
Bathroom, Kitchen, Toilet, Corridor, School, Living room, Bedroom, Spa room, Hotel
Hospital, Meeting room, Showcase, Warehouse, Office, Supermarket, Department store
1.Payment T/T , L/C , Paypal , Western Union. small order is 100%, for large amount,30% down payment, 70% balance before shipping
2. MOQ: 5 pcs/carton(item) , Discounts are offered based on order quantity.
3. Delivery time: Sample in 3- 7 working days, large order 7-15 working days
4. Supply Ability: 100,000 Piece/Pieces per Month
5. Any inquire about our product will be reply in 8 hours
Shenzhen Hofo Technology Co.,Limited various products range from led ceiling light, led wall light, led high bay lights, led street lights,led flood lights, led tunnel lights, led panel light, as well as led tube, led strip etc. Having high skills of R&D team, We got the license of ISO9001:2008, all products has pass CE, RoHS SAA IK10 approval etc.
If interested in our products, please do not hesitate to send us inquire.
Our excellent sales are always at your service.
