Click on the image to view the original image
- Item Type:
- Ceiling Lights
- Light Source:
- LED
- Install Style:
- Surface Mounted
- Input Voltage(V):
- AC100-277V
- Lamp Luminous Flux(lm):
- 1600
- CRI (Ra>):
- 80
- Working Temperature(℃):
- -40 - 60
- Working Lifetime(Hour):
- 50000
- Lamp Body Material:
- Aluminum
- IP Rating:
- IP65
- Certification:
- CE, EMC, LVD, RoHS, SAA
- Place of Origin:
- Guangdong, China
- Brand Name:
- hofoled
- Model Number:
- HF-CL20R300
- Application:
- HOTEL
- Base Material:
- Aluminum
- Cover Material:
- Plastic
- LED Light Source:
- Epistar
- Warranty:
- 3 years
- Aluminum housing color:
- black,white,grey color
- power:
- 15w 20w 30w 40w available
- Product Size:
- 300*300*85mm
- IK Rating:
- IK10
- Material:
- Die-casting aluminum, milky PC cover
- Function:
- can add motion sensor/Dimmable
- Style:
- round led ceiling light
- Product name:
- led bulkhead light,led bathroom light
- Supply Ability:
- 100000 Piece/Pieces per Month
- Packaging Details
- normally inner white box, color box is customized by customer
5 pcs/ Carton, 12 KG by dimension, G.W:9.5 KG
- Port
- Shenzhen
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 200 >200 Est. Time(days) 7 To be negotiated
CE RoHS SAA motion sensor led bulkhead lighting outdoor plastic
Same diameter 300mm for 20W 30W 40W, Black,White, Grey colors for choose
| Power Consumption | 20W | 30W | 40W |
| Luminous Flux | 1600Lm | 2400Lm | 3200Lm |
| Light Source | High Power SMD LED | ||
| CRI | 85 | ||
| Chip Type | SMD2835 | ||
| Driver Input Voltage | 85~265v AC 50 / 60Hz | ||
| Colour Temperature (CCT) | 2800K~3100K | 3800K~4250K | 6000K~6500K |
| Power Factor | 0.95 | ||
| Rated Life (L70) | 50,000Hrs | ||
| Working Temperature | -10C ~ 40C | ||
| Storage Temperature | -20C ~ 80C | ||
| Working Humidity | 5% ~ 95%RH | ||
| Lamp Housing | Aluminium Alloy | ||
| Lens | Poly Carbonate (PC) | ||
| Finish | Powder Coat Black | ||
| Dimensions | 300*300*85mm | ||
| Installation | Wall Mounted, Surface mounted | ||
| Installation | IP65 Waterproof | ||
| Additional | CE ROHS SAA IK10 Approved | ||
2D LED Bulkhead Light IP65 Features:
1. Die-casting aluminum lamp body, excellent heat dissipation
2. IP65 waterproof, dustproof for indoor and outdoor lighting
3. Milky white PC cover, high impact resistance, IK10 approval
4. 304 Stainless steel hexagon socket head cap screws
5. Can be installed with a motion sensor, RF,PIR sensor
6. Available for emergency function 3 hours or emergency+sensor
7. Black / white / grey aluminum housing color available
8. Energy saving, not emitting UV and IR, no RF interference
Bulkhead LED Light Photos:
Round LED Bulkhead Light Photos:( 3 colors for choose)
hofoled Model:HF-CL15R300(15W), HF-CL20R300(20W), HF-CL30R300(30W),HF-CL40R300(40W)
Square led bulkhead light
hofoled Model: HF-CL20S300 (20W), HF-CL30S300(30W),HF-CL40S300(40W)
hofoled Model:HF-CL15W,HF-CL20R275,20W &15W
LED Bulkhead fitting Functions:
1. Can add Microwave / Motion Sensor Function
Microwave Motion Sensor are available to add inside the led ceiling light, The Microwave Motion Sensor is an innovative motion sensor, switch on the light on detection of movement, and switch off after a hold time when there is no motion detected. As built-in daylight sensor can read brightness value, the sensor does not switch on the light if with sufficient natural light.
Detection area: from 2m to 10m
Hold time: 5s, 30s, 90s, 3min, 20min, 30min
Daylight sensor: 2LUX, 10LUX, 25LUX, 50LUX, Disable
2. Emergency function:
Emergency Time: 3 Hours
Lithium Battery Capacity
With main power AC100-277V, we offer 15W or 20W, When electricity cut off, Emergency power 8 W will work immediately.
3. Microwave/Motion Sensor + Emergency function 3 hours:
HOFOLED LED Ceiling Light/LED Bulkhead light/LED wall light certification
Quality Control of LED Ceiling Light
All of the led lamps from hofoled factory will be tested and aging for 24 hours to ensure
quality reliability before ship out.
Our QC team have been in lighting field experiment and exploration for more than 6 years.
Ceiling Light LED Applications:
Bathroom, Kitchen, Toilet, Corridor, School, Living room, Bedroom, Spa room, Hotel
Hospital, Meeting room, Showcase, Warehouse, Office, Supermarket, Department store
Bulkhead LED Light Applications:
Bathroom, Kitchen, Toilet, Corridor, School, Living room, Bedroom, Spa room, Hotel
Hospital, Meeting room, Showcase, Warehouse, Office, Supermarket, Department store
Payment Terms:
1.Payment T/T , L/C , Paypal , Western Union. small order is 100%, for large amount,30% down payment, 70% balance before shipping
2. MOQ: 10 pcs, Discounts are offered based on order quantity.
3. Delivery time: Sample in 3- 7 working days, large order 7-15 working days
4. Supply Ability: 100,000 Piece/Pieces per Month
5. Any inquire about our product will be reply in 8 hours
