- Item Type:
- Ceiling Lights
- Light Source:
- LED
- Install Style:
- Surface Mounted
- Input Voltage(V):
- 100-277Vac
- Lamp Luminous Flux(lm):
- 1800
- CRI (Ra>):
- 80
- Working Temperature(℃):
- -40 - 60
- Working Lifetime(Hour):
- 50000
- Lamp Body Material:
- Aluminum
- IP Rating:
- IP65
- Certification:
- CE, EMC, LVD, RoHS, SAA
- Place of Origin:
- Guangdong, China
- Brand Name:
- hofoled
- Model Number:
- HF-CL20R300
- Application:
- WAREHOUSE, Hotel,bathrom,corridor,bacony,stairs,spa,toilet
- Base Material:
- Aluminum
- Cover Material:
- Plastic
- LED Light Source:
- SMD2835
- Lamp Luminous Efficiency(lm/w):
- 80
- Warranty:
- 3 years
- Aluminum housing color:
- black,white,grey color
- power:
- 12w 15w 20w 30w 40w available
- Product Size:
- 300*300*85mm
- Install type:
- wall mounted,ceiling mounted,surface mounted
- Material:
- Die-casting aluminum, milky PC cover
- Power factor:
- 0.90
- Supply Ability:
- 50000 Piece/Pieces per Month
- Packaging Details
- normally innerbox then carton box,
If request color box is customized by customer
5 pcs/ Carton, 12 KG by dimension, G.W:10KG
- Port
- Shenzhen
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 200 >200 Est. Time(days) 7 To be negotiated
led outdoor ip65 surface mount light fixture
Same diameter 300mm for 20W 30W 40W, Black,White, Grey colors for choose
| Power Consumption | 20W | 30W | 40W |
| Luminous Flux | 1800Lm | 2700Lm | 3600Lm |
| Light Source | High Power SMD LED | ||
| CRI | 85 | ||
| Chip Type | SMD2835 | ||
| Driver Input Voltage | 85~265v AC 50 / 60Hz | ||
| Colour Temperature (CCT) | 2800K~3100K | 3800K~4250K | 6000K~6500K |
| Power Factor | 0.95 | ||
| Rated Life (L70) | 50,000Hrs | ||
| Working Temperature | -10C ~ 40C | ||
| Storage Temperature | -20C ~ 80C | ||
| Working Humidity | 5% ~ 95%RH | ||
| Lamp Housing | Aluminium Alloy | ||
| Lens | Poly Carbonate (PC) | ||
| Finish | Powder Coat Black | ||
| Dimensions | 300*300*85mm | ||
| Installation | Wall Mounted, Surface mounted | ||
| Installation | IP65 Waterproof | ||
| Additional | CE ROHS SAA IK10 Approved | ||
LED Ceiling Light IP65 Features:
1. Die-casting aluminum lamp body, excellent heat dissipation
2. IP65 waterproof, dustproof for indoor and outdoor lighting
3. Milky white PC cover, high impact resistance, IK10 approval
4. Stainless steel hexagon socket head cap screws
5. Can be installed with a motion sensor, RF,PIR sensor
6. Available for emergency function, from 1 to 4 hours
7. Black / white / grey aluminum housing color available
8. Energy saving, not emitting UV and IR, no RF interference
Round LED Ceiling Light Photos:
Model:HF-CL20R300(20W), HF-CL30R300(30W),HF-CL40R300(40W)
microwave sensor are available to add inside the led ceiling light:
Hofoled Surface mounted led ceiling light Advantages:
60-70% energysaving, longer lifetime up to 50 000 hours than incandescent and fluorescent, instant
start: starts right away no matter the temperature or conditions, visual attractive with quality appearance,
material: Aluminum, no mercury contained, reduce carbon emissions, UV and IR free, producing minimum
heat,no additional fixtures needed, CE/RoHS/SAA approval
Factory production flow & Aging area:
Warm white: 2800-3000K
Natural white: 4000-4500K
Cold white: 5500-6500K, other Color temperature is available
Ceiling LED Light Applications:
Bathroom, Kitchen, Toilet, Corridor, School, Living room, Bedroom, Spa room, Hotel
Hospital, Meeting room, Showcase, Warehouse, Office, Supermarket, Department store
1.Payment T/T , L/C , Paypal , Western Union. small order is 100%, for large amount,30% down payment, 70% balance before shipping
2. MOQ: 10 pcs, Discounts are offered based on order quantity.
3. Delivery time: Sample in 3- 7 working days, large order 7-15 working days
4. Supply Ability: 50,000 Piece/Pieces per Month
5. Any inquire about our product will be reply in 8 hours
