- Item Type:
- Ceiling Lights
- Light Source:
- LED
- Install Style:
- Surface Mounted
- Input Voltage(V):
- AC100-240V
- Lamp Luminous Flux(lm):
- 1800
- CRI (Ra>):
- 80
- Working Temperature(℃):
- -30 - 50
- Working Lifetime(Hour):
- 50000
- Lamp Body Material:
- Aluminum
- IP Rating:
- IP65
- Certification:
- CE, EMC, LVD, RoHS, SAA
- Place of Origin:
- Guangdong, China
- Brand Name:
- Hofoled
- Model Number:
- HF-CL20R300D
- Application:
- HOTEL, Corridor,school,stair,bacony,passageway
- Base Material:
- Aluminum
- Cover Material:
- Plastic
- LED Light Source:
- SMD2835
- Color:
- Black,white
- Product name:
- Led Bulkhead Light
- Keyword:
- dimming led bulkhead light, dimming bulkhead
- Material:
- Die-casting Aluminum,PC cover
- Warranty:
- 2 Years
- Type:
- Adjustabe
- Power factor:
- 0.90
- Power:
- 12w 15w 20w 30w 40w
- Supply Ability:
- 10000 Piece/Pieces per Month
- Packaging Details
- N.G 1.8KG
5pcs a carton
G.W 10KG
Package: 51*33*34CM
- Port
- Shenzhen
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 200 >200 Est. Time(days) 7 To be negotiated
20Watt IP65 White Base Microwave SENSOR 10-100% DIMMING Bulkhead Light
Model | HF-CL20R300D | CRI | >80 |
Power | 20W | Power Factor | >0.9 |
LED chip | Epistar SMD | Color temperature | 3000K/4000K/6000K |
Lumens | 90lm/w 1800LM | Function | dimming sensor 10% 25% |
Input Voltage | 100-240Vac | Certification | CE RoHS SAA IP65 IK1O |
1. Material: Die-casting aluminum lamp body, Milky white PC cover
2. IP rate: IP65 waterproof, dustproof for indoor and outdoor lighting
3. Screw: Stainless steel hexagon socket head cap screws
4. Color: Black / white / grey housing color
5. Function: 10% 25% dimming microwave sensor, 3-step dimming
Corridor 10% - 100% Dimming Feature 3 MODE Settings
Stand-by dimming level is optional, 10% / 25%.
Integration of microwave motion sensor, daylight sensor and LED power supply.
Automatic switching and dimming based on motion and light level.
Constant current can be set via DIP switch.
Compact size makes the drivers suitable to fix within most LED ceiling lights.
Detection area, time delay and daylight threshold can be precisely set via DIP switch.
Operating voltage | 220~240Vac,50/60Hz |
Output constant current | 600mA, set via DIP switch |
Output voltage | 22-40Vdc(600mA) |
Efficiency | ≥84% (@Full load) |
Power factor | >0.9 (@Full load) |
HF system | 5.8Ghz±75Mhz,ISM wave band |
Transmitting power | ≤0.5mW |
Power consumption | ≤0.5W (standby) |
Detection range | 4m(@ 3m mounting height) |
Detection area | 50%/ 100% |
Hold time | 5s/ 90s/ 3min/ 10min |
Stand-by period | 0s/ 30s/ 10min/ +∞ |
Daylight sensor | 5lux/ 15lux/ 50lux/ Disable |
Stand-by DIM level | 10%/ 25% |
Mounting height | 6m Max. |
Motion detection | 0.5~3m/s |
Detection angle | 150° (Wall installation) |
Working temperature(Ta) | -25°C ~ 45°C |
Size (ø x H) | 82x28.5mm |
Bathroom, Kitchen, Toilet, Corridor, School, Living room, Bedroom, Spa room, Hotel
Hospital, Meeting room, Showcase, Warehouse, Office, Supermarket, Department store
1. Payment T/T , L/C , Paypal , Western Union small order is 100%, for large amount,30% down payment, 70% balance before shipping
2. MOQ: 5 pcs , Discounts are offered based on order quantity.
3. Delivery time: Sample in 3- 7 working days, large order 7-15 working days
4. Supply Ability: 10,000 Piece/Pieces per Month
5. Any inquire about our product will be reply in 8 hours
