Click on the image to view the original image
- Item Type:
- Ceiling Lights
- Light Source:
- LED
- Install Style:
- Surface Mounted
- Input Voltage(V):
- AC100-277V
- Lamp Luminous Flux(lm):
- 1600
- CRI (Ra>):
- 80
- Working Temperature(℃):
- -40 - 60
- Working Lifetime(Hour):
- 50000
- Lamp Body Material:
- Aluminum
- IP Rating:
- IP65
- Certification:
- CE, EMC, LVD, RoHS, SAA
- Place of Origin:
- Guangdong, China
- Brand Name:
- hofoled
- Model Number:
- HF-CL20R300
- Application:
- WAREHOUSE, corridor
- Base Material:
- Aluminum
- Cover Material:
- Plastic
- LED Light Source:
- SMD2835
- Lamp Luminous Efficiency(lm/w):
- 80
- Product name:
- led ceiling lamp corridor
- Type:
- Surface Moutned
- Keyword:
- motion sensor ceiling lamp corridor
- Material:
- Aluminum+PC
- Warranty:
- 2years
- Proudct Size:
- 300*300*85mm
- Beam angle:
- 120 Degree
- Supply Ability:
- 10000 Piece/Pieces per Month led ceiling lamp corridor
- Packaging Details
- Box size:310*310*100mm
Carton:510*330*340mm
5pcs/Carton
- Port
- shenzhen
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 300 >300 Est. Time(days) 7 To be negotiated
ON-OFF Function
The products provide ON-OFF and steps dimming function for LED lighting, users
can select the right function according to different applications.
 | | |
With sufficient ambient light, the sensor does not switch on the lamp. | With insufficient ambient light, the sensor switches on the lamp | After hold time, the lamp gradually dims down if no motion detected. |
Specification:
| Power: | 20Watt |
| Model: | HF-CL20R300 |
| Input voltage: | 100-277VAC/50-60Hz |
| LED resource: | SMD2835 |
| Luminous: | 1600 lm |
| IP Rating: | IP65 waterproof |
| Beam angle: | 120 degree |
| Color rendering index: | Ra > 80 |
| Color temperature: | Warm white:3000K, Nature white:4000K, Cool white:6000K |
| Environment temperature: | -40/+60℃ |
| Dimensions: | Ø300 x 85 mm |
| Certification: | CE RoHS SAA |
| Install style: | wall mounted,surface mounted |
Product Description:
| |
| |
Features
1. Die-casting aluminum lamp body, excellent heat dissipation.
2. Milky white PC cover, high impact resistance,IK10 approval
3. IP65 waterproof, dustproof for indoor and outdoor lighting
4. 304 Stainless steel hexagon socket head cap screws
5. Can be installed with a microwave motion sensor, dimming sensor
6. Available for emergency function, 1-3 hours
7. Black / white / grey aluminum housing color available
8. Glow wire test at 850 ℃ pass NF EN 60695-2-1,VDE approval.
9. Install style: Wall mounted, Surface mounted
10. Certification: CE RoHS SAA IP65 IK10
Application:
Certifications:
Payment Terms:
1. payment T/T , L/C , Paypal , Western Union small order is 100%, for large amount,30% down payment, 70% balance before shipping
2. MOQ: 10 pcs , Discounts are offered based on order quantity.
3. Delivery time: Sample in 3- 7 working days, large order 7-15 working days
4. Supply Ability: 10,000 Piece/Pieces per Month
5. Any inquire about our product will be reply in 8 hours
