Model JLEB-36-US Features: LED Emergency Battery Pack for LED Model-JLEB series(36W, Internal battery pack) JIMING LED emergency battery pack will operate LED lighting fixtures between 3-40VDC including LED panel, LED down light, LED ceiling light and the other LED fixtures with external AC drivers not exceeding 44W(JLEB-44 series) or 72W(JLEB-72 series). The LED lighting will be illuminated, at reduced output, for a minimum of 90 minutes. JIMING also provide a high lumen solution (JLEB-20-H) which can operate LED tube light, LED bulb and the other lighting fixtures need a high lumen output, not exceeding 20W. The LED lighting will be illuminated, at 100% output, for a minimum of 90 minutes.
TECHNICAL DATA: Mode of Operation: Maintained Input Voltage: 100~277VAC 50/60HZ Input power: 2.8W Battery: 4.8V 2300mAh Nickel Cadmium Battery(Internal) Output voltage: 3-40VDC Output current: <200mA Lumen output: 15% Lamp used: 36W LED tubes or Down lights(Please Refer to Supplier) Operating Temperation: 0℃~40℃ Charger: Solid-state Electronics Provide High Reliability with Trickle Charge-Facility. Indication: Red LED Backup time: ≥90minutes Recharge time required: 24hous Protection: Low-Voltage Cut-Off to prevent Over-Discharge of Battery
The JLEB series Emergency Ballasts for LED Model allow the same lighting fixture to be used for both normal and emergency operation. In the event of a power failure, the JLEB switches to the emergency mode and operates the LED tubes or Down lights for a minimum of 90 minutes. The unit with an external battery, charger and inverters IN A SINGLE PACKAGE. The JLEB can be mounted in the wireway or on the top of fixture. And UL, cUL certificate is pending.
JLEB-36-US 36W cUL&UL Approved emergency light driver -China TOP 1 Emergency Light Driver Factory Since 1967 -iemergencylight.com
Company Information
emergency light led driver -JLEB-36-US 36W cUL&UL Approved 6523D
Production
emergency light led driver -JLEB-36-US 36W cUL&UL Approved 6523D
Packaging & Shipping
Our Services
emergency light led driver -JLEB-36-US 36W cUL&UL Approved 6523D
Click on the image to view the original image
