| Product Name: | Emergency Ballast-JEB series | Packing Information | ||||
| Model No.: | JEBT5-800 | Packing: | White box | |||
| Main Specification: | 25W,32W,40W T8,34W,40W T12, 14W,21W, 28W T5,39W,54W T5HO,18W,24W,36W,40W,50W CFL(4pin)Fluorescent lamp, 90mins, Ni-cad 6V2500mAh | Carton: | L(cm) | W(cm) | H(cm) | |
| Carton Size: | 48.5 | 18.5 | 23.5 | |||
| Product Size: | Carton CBM: | 0.021M3 | ||||
| MOQ: | 1000PCS | Q"TY/INNER BOX: | PCS | |||
| Lead Time: | 35 days | Q"TY/CTN: | 12PCS | |||
| Sample Delivery Time: | 3~10 days | Gross Weight: | 11.9KGS | |||
| Remarks: | Net Weight: | 10.9KGS | ||||
| Container Loading Q"TY(PCS): | 1*20" | 1*40" | 1*40" HQ | |||
| 15714 | 32857 | 38286 | ||||
| Model JEBT5-800 Features: Emergency Ballast-JEB series Fluorescent emergency ballast with painted durable steel casing. Nickel-Cadmium battery, charger and inverter circuit contained. UL approved, Meets or exceeds all NEC and Life Safety Code emergency lighting requirements. Cold starts and operates specified lamp types, LED Charge indicator light and push-to-test switch. 120/277 VAC dual voltage operation, 90 minutes operation. TECHNICAL DATA: Mode of Operation: Maintained Input Voltage: 120/277VAC 60HZ Battery: 6V 2500mAh Nickel Cadmium Battery Lamp used:one 25W,32W,40W T8,34W,40W T12, 14W,21W, 28W T5,39W,54W T5HO,18W,24W,36W,40W,50W CFL(4pin)Fluorescent lamp.(Please Refer to Supplier) Operating Temperation: 0℃~50℃ Charger: Solid-state Electronics Provide High Reliability with Trickle Charge-Facility. Indication: Red LED Backup time: ≥90minutes Compliance: UL, cUL Protection: Low-Voltage Cut-Off to prevent Over-Discharge of Battery The JEB series Emergency Ballasts allow the same lighting fixture to be used for both normal and emergency operation. In the event of a power failure, the JEB switches to the emergency mode and operates the fluorescent lamps or PLC tubes for a minimum of 90 minutes. The unit contains a battery, charger and inverters IN A SINGLE PACKAGE. The EBAL can be mounted in the wireway or on the top of fixture. And is UL, cUL approval. | ||||||
| iemergencylight.com -China TOP 1 Emergency Lighting / Exit Sign / Emergency Ballast / LED Emergency Driver Manufacturer Since 1967. For more details, please contact our sales team! Thanks! | ||||||
