concrete power trowel machine for sale

Click on the image to view the original image

Product：	views：5concrete power trowel machine for sale
Branch：	HWGK
Type：	GX690
Size：	65X40X50 cm
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:19

Product Details

Overview

Quick Details

Power Source:: Gasoline

Power(W):: 22HP

Dimension(L*W*H):: 1500*900*600mm

After-sales Service Provided:: Free spare parts, Video technical support, Online support, No after-sales service, Field installation, commissioning and training, No overseas service provided

Warranty:: 2 Years

Applicable Industries:: Manufacturing Plant, Construction works , Energy & Mining

Condition:: New

Place of Origin:: Shandong, China

Brand Name:: HWGK

Voltage:: Gasoline Engine

Weight:: 230KG

Certification:: ISO

UNIQUE SELLING POINT:: Easy Maintenance

Name:: used concrete power trowelmachine for sale

Type:: GX690

Blade size:: 2*150*320mm

Delivery time:: 7 Days

Packing:: Clients Request

Working diameter:: 1170mm

Speed:: 70-125 Rpm

Fuel Tank:: 3.6L

Function:: Polishing

Packaging & Delivery

Selling Units:: Single item

Single package size:: 65X40X50 cm

Single gross weight:: 65.0 kg

Package Type:: wooden case or as your requirement

Lead Time:

Quantity(Piece)	1 - 1	>1
Est. Time(days)	7	To be negotiated

used concrete power trowel machine for sale

Product Description

Usage

This equipment is the newest concrete surface, coarse, fine trowel machines. After construction of the equipment the surface is more smooth, it can greatly improve the density of the concrete surface, wear resistance.IT can also greatly improve the effectiveness, efficiency can be improved compared with manual operation several times over. This equipment is widely used in concrete pavement, floor, airports, floor, etc.

JN189 type driving type power trowel has the following advantages:

1. Drive type operation, greatly reducing the labor intensity and improve work efficiency.

2. Install two simultaneous disk wiping, quick to mention pulp.

3. The two-way ten lobes, weight 400kg, on the ground better compaction effect.

4. mechanical steering operating system, responsive, easy to operate, and comfortable.

5. having a variable gear, high-grade smear speed of up to 160 rev / min, so that the light yield faster, better, low-grade pulp can wipe disk mention more powerful.

6. The equipment high-horsepower electric start engine, to provide a strong and reliable power.

7. A safety shut-off switch that can rapidly turn off the engine, to ensure safety.

8. The control screw to adjust the blade angle.

9. sprinkler and lighting designed to facilitate construction.10. fitted with a lift walking round, easy to change smear, for wiping the disc as well as walking.

Parameter

Trowel plate diameter	Trowel plate speed	Motor power	Gasoline power	Number of blades	Model	Weight	size(mm)
620mm	60-100r/min	2.2-3KW	5.5-6.5PS	4pieces	Motor Y90L-4	65kg	1500×620×600
800mm					Motor Y90L-4	80kg	1500×800×600
900mm					Gasoline LF168F-2	100kg	1500×900×600
1000mm					Gasoline LF168F-2	105kg	1500×1000×600
