Product Description
Factory price electric pile driver with good quality
| Model | HWZG-600L | ||
| Pile length | 0-6000 | mm | |
| Duplex gear pump pressure | 25 | Mpa | |
| Duplex gear pump displacement | 40/40/25 | ml/r | |
| Hydraulic system pressure | 20 | Mpa | |
| Main valve flow | 150 | L/Min | |
| Overall Machine weight | 6 | T | |
| Diesel engine power | 85 | KW | |
| Rated Speed | 2400 | R/min | |
| Starting Voltage | 24 | V | |
| Rotation angle | 360 | ° | |
| Rotation semi diameter (rotating shaft to Pod distance) | 2150 | mm | |
| Effective press pile stroke | 0-5000 | mm | |
| Dimension(LXWXH) | 6300×2150×2300 | mm | |
| Track shoe | 350 | mm | |
| Walking motor total displacement | 1575 | ml/m | |
| Motor Head Hamming Force | 1700 | J | |
| Walking motor rotate speed | 50 | r/min | |
| Operating Speed (m/min) | 1.5 | 90s/per pile | |
| Number of impacts / strokes per 1 minute | 900 | times/min | |
| Maximum lengh of Piles to be rammed | 6 | M | |
| Walking speed | 5-10 | Km/hr | |
| Gradeability | 0-35 | ° | |
| Oil tank capacity | 20 | L | |
| Daily production on 4.5m | 210 | Pieces | |
| Daily production on 2.5m | 260 | Pieces | |
| Weather limitation | We have exported to your country ,suitable for your cuntry | ||
| Soil limitation on freezed soil | Can work on hard soil | ||
