Product Features:
1). Best Matched Drive System
Adopted Yuchai /Deutz Engine that features power reservation ,low consumption and good power performance.
2). Advanced &Reliable Brake System
Axle Housing and hub reduction adopted separate structue that features low maintenance cost.
Dual piping service brake with caliper disc brake ensure safety and reliability.
3).High Efficiency Hydraulic System
Advanced radiation system of hydraulic system is adpoted for working under high ambient temperature.
Hydraulic tank with vacuum device ensures easy maintenance and fixing of hydraulic system.
Product Parameter:
Main Specifications | |
Rated Load Capacity | 2000 kg |
Operating Weight | 4200kg |
Bucket Capacity | 0.7m³ |
Bucket Width | 1820mm |
Dimensions L*W*H | 5300x2050x2750 mm |
Engine | |
Model | YUNNEI |
Rated Power | 55kW |
Max. Torque | 192Nm |
Operating Specifications | |
Max. Drawbar Pull | 45 kN |
Max. Breakout Force | 43 kN |
Hydraulic System Pressure | 16 MPa |
7.6 s | |
Steering System | |
Steering Angle Left/Right | 36º±1º |
Minimum Turing Radius (Over Rear Tire) | 3700 mm |
Minimum Turing Radius (Over Bucket ) | 3900 mm |
Transmission |
|
Type | Counter shaft power shift |
Speed Gears | F2/R2 |
Axle | |
Brand | Bei Lian |
Front Axle | Fixed with calipers |
Rear Axle | Fixed with Osc.frame and calipers |
Brake System | |
Service Brake | Dry & calipers, air-to-oil brake |
Parking Brake | Drum-type shoe brake,spring applied &air released
|
Tires | |
Size | 16/70-20 |
Type | Bias-ply |
