• Based on Led or infrared Led Technologies
• Customizable for both AC and DC conditions.
• Customizable for steady burning or flashing mode
• Multiple light elements in the source reduce the chances of a complete blackout which
could be caused in case of a single source failure.
• All hardware of obstruction lights are made of corrosion resistant metals.
• Bird spikes for protection against droppings.
• With NVG(Night Vision Goggles), this should be customized(optional)
• Built in photocell, which can switch ON/OFF the lights automatically at dawn and dusk (optional)
• Use of quality components and sophisticated technology reduce chances of maintenance
and replacement.
• Low power consumption, which leads to huge savings on electricity bills.
• LED light source ensures long lifetime, maintenance free
• Built-in anti electrophoresis impact module, with lightning/surge protection
• Resistant to shock and vibration.
• No RF Radiations, EMC Compliant
• Reversed Polarity Protected(DC Type)
• Corrosion resistant lamp & housing-suitable for off-shore use
• Bottom cable entry-ease of mount, mount accessories available
• Self-contained compartment-eliminates additional box
• Flashing rate adjustable
• With dry contact alarm, it will give an alarm in case of power and light failure
• Available both in single and double type
• 5 years warranty
Specifications:
LIGHT OUT-PUT | DL32S |
Effective Intensity | 32 Candela |
Vertical Divergence | 10 Degree |
Horizontal out-put | 360 Degree |
LED Color | Red |
LED Lifespan | 100,000 Hours |
OPERATION | |
Flash Pattern | Steady burning or Flashing(20-60times/min) |
POWER SUPPLY | |
Input voltage | 85-265VAC;20-60VDC, 12VDC |
Frequency | 50Hz ~ 60Hz |
MECHANICAL STRUCTURE | |
Lens | Polycarbonate, UV Stabilize |
Body | Die-casting Aluminum |
Water-proof | IP65 |
Weight | 0.9KG |
Dimensions | 159mmx245mm |
Mounting Size | Threaded 3/4"" bottom hub |
Temperature Range | -40℃ ~ +55℃ |
Relative humidity | 100% with condensation |
Wind speed | Up to 150mph(240kph) |
Warranty | 5 year |
Optional | Available in flashing pattern(40FPM) |
Order Codes
| Series | Single/Double | AC/DC | Voltage | Flashing | Photosensor | Alarmrelay |
DL32 | S | A | 12 | F | P | R |
|
| D | 24 |
|
|
|
|
|
| 48 |
|
|
|
|
|
| 110 |
|
|
|
|
|
| 220 |
|
|
|
