Specifications:
LIGHT OUT-PUT | DL100S(Single) |
Effective Intensity | 100 Candela |
Vertical Divergence | 10 Degree |
Horizontal out-put | 360 Degree |
LED Color | Red |
LED Lifespan | 100,000 Hours |
OPERATION | |
Flash Pattern | Steady burning(default)/Flashing (20-60times/min) |
POWER SUPPLY | |
Input voltage | 85-265VAC;20-60VDC;12VDC |
Frequency | 50Hz ~ 60Hz |
MECHANICAL STRUCTURE | |
Lens | Polycarbonate, UV Stabilize |
Body | Die-casting Aluminum |
Water-proof | IP65 |
Weight | 0.9KG |
Dimensions | 159mmx245mm |
Mounting Size | Threaded 3/4"" bottom hub |
Temperature Range | -40℃ ~ +55℃ |
Relative humidity | 100% with condensation |
Wind speed | Up to 150mph(240kph) |
Warranty | 5 years |
Optional | Available in flashing pattern(40FPM) |
Order Codes
| Series | Single | AC/DC | Voltage | Flashing | Photosensor | Alarmrelay | Pattern(For double light only) |
DL100 | S | A | 12 | F | P | R | ST |
|
|
| 48 |
|
|
|
|
|
|
| 110 |
|
|
|
|
|
|
| 220 |
|
|
|
|
