Specifications
LIGHT OUT-PUT | |
Peak Intensity | 2000 Candela |
Vertical Divergence | -1° :950cd, Centering at 0.5° |
Horizontal out-put | 360 Degree |
LED Color | Red |
LED Lifespan | 100,000 Hours |
OPERATION | |
Flash Pattern | Steady-burning or flashing(20-60times/min) |
POWER SUPPLY | |
Input voltage | 85VAC ~ 265VAC, 12VDC,20-60VDC |
Frequency | 50Hz ~ 60Hz |
Power consumption | 40W with steady mode; 5W with flashing |
MECHANICAL STRUCTURE | |
Lens | Polycarbonate, UV Stabilize |
Body | Die-casting Aluminum |
Water-proof | IP67 |
Weight | 11KG |
Temperature Range | -40℃ ~ +55℃ |
Relative humidity | 100% with condensation |
Dimensions | 210mm H, 226mm Diameter |
Warranty | 5 years |
Optional | Available with built-in photocell |
Order Codes:
Series | Steady / flashing | AC/DC | Voltage | Flashing | Photo sensor | Alarm relay |
ZG2KD | C (steady) | A | 12 | F | P | R |
| B (flashing) | D | 24 |
|
|
|
|
|
| 48 |
|
|
|
|
|
| 110 |
|
|
|
|
|
| 220 |
