Hot Sale Flexible Snake FRP Fiberless Duct Rodders
Click on the image to view the original image
Product: views:6Hot Sale Flexible Snake FRP Fiberless Duct Rodders
Branch: Lanyu
Unit Price: Negotiated
Min.Order:
Supply:
Delivery: Shipment within days since the date of payment
Valid until: Long Term
Updated on: 2019-10-16 19:38
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Hebei, China
Brand Name:
Lanyu
Model Number:
DR-001
Application:
tools for pulling cable
Surface Treatment:
plastic coasted
Technique:
pultrusion
Dimensions:
4-18mm
Product name:
Hot Sale Flexible Snake FRP Fiberless Duct Rodder
Color:
yellow,black,red,green,white etc
Assembly:
wheel, metal frame
Length:
10-500m
Diameter:
4-18mm
Special Using:
tracing,cable push pull tools
Material:
E-glass fiber inside and ABS outer layer coated
Drawing head:
Copper or high carbon steel Q345
Supply Ability
Supply Ability:
3000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Fiberglass push pull duct rods/Fiberglass Duct Rodder package:carton or pallet
Port
Tianjin
Lead Time:
Shipped in 20 days after payment
Product Description

Hot Sale Flexible Snake FRP Fiberless Duct Rodders

Lanyu company supplyyou super quality fiberglass push pull snake conduit duct rodder with factory price which are made of frp duct rods.Good flexible and tracing make the duct rods have good effective to finish the snake and electric conduction in the electric cable tubes.

Name
Duct Rodder, Snake rod, Push Pull Rod
FRP rod diameter
φ4mm--φ18mm,
Length
30m--500m
Min Bend Radius
250mm,330mm
Glass Fiber Density
210kg/m, 245kg/m
Breaking tension
2400kg,4200kg
Working Temperature
-40°C--80°C
Frame size
1300mm x 450mm x 1330mm
1200mm x 420mm x 1220mm
980mm x 350mm x 1000mm
680mm x 240mm x 700mm
4200mm x 1800mm x 400mm

Information about Lanyu FRP Cable Push Duct Rodder

FRP rod information

1. Light weight, durable, good resistance to chemical and corrosion.
2. High tensile strength and bending properties to make it go through narrow pipes easily.
3. good temperatures adaptability, it will not soften in hot weather nor become brittle in cold weather, its usability will not be affected by temperature.
4. Rod jacket: developed composite materials, hard, smooth and wear-resistant.
5. meter marks are available
6. Rod colors: yellow, other colors are optional

Frame and reel information

1. Equipped with brake device, the rotating or stopping of the rod can be easily operated by hand.
2. Tilting type handle, convenient for pushing and pulling.
3. Guide roller and fixed ring: fix the rod end; protect the rod jacket from being scratched.
4. Frame color: yellow, other colors are available.

Detailed Images
Packing & Delivery
Related Products
FAQ & Contacts

Q: Are you trading company or manufacturer ?
A: We are manufacturer with our own factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. Or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge. And the freight cost will on the buyer"s side.

Q: What is your terms of payment ?
A: Payment<=USD1000, 100% in advance. Payment>=USD1000, 30% T/T in advance ,balance before shipment.
