Home > Products > 6mm 150m yellow fiberglass duct rodders cable rodding fiberglass wheel
6mm 150m yellow fiberglass duct rodders cable rodding fiberglass wheel
Click on the image to view the original image
Product: views:26mm 150m yellow fiberglass duct rodders cable rodding fiberglass wheel
Branch: LANYU
Unit Price: Negotiated
Min.Order:
Supply:
Delivery: Shipment within days since the date of payment
Valid until: Long Term
Updated on: 2019-10-16 19:41
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Hebei, China
Brand Name:
LANYU
Model Number:
LANYU00
Application:
push pulling rod tools
Surface Treatment:
ABS coated
Technique:
pultrusion
Material:
glass fiber inside and ABS outer layer coated
Product name:
fiberglass conduit rodders used duct rodders traceable duct rodders
Color:
yellow blue white green orange
frame:
galvanized steel frame or spray paint
Special using:
tracing,cable push pull tools
length:
50 100 150 200 250 300m or customization
diameter:
4.5-16mm
Temperature:
-40℃ to +80℃
Quality:
good
delivery time:
within 10days after payment
Packaging & Delivery
Packaging Details
carton
Picture Example:
package-img
package-img
Lead Time:
Quantity(Sets)1 - 100 >100
Est. Time(days)20To be negotiated
Video Description
Product Description

fiberglass conduit rodders used duct rodders sale traceable duct rodders

Great Rigidity Fiberglass Push Pull,FRP duct rod, Cable duct rodder is selected as a special tool for pulling electric cables and optical fibre cables in telecom, power industries, buildings and many other fields.

The rod is made of fiberglass and high strength resin at high temperature, it is coated by high density polyethylene engineering plastic as its protected layer, which makes the duct rodder cover sliding on surface, durable, corrosion resistant and has good insulation performance, these make it safe for using in cable occupied duct. Along with pull head and handcart, it features easy to move and operate. The fiberglass duct rodder will be equipped with different size of reels in accordance with the length of the rod, there are wheels on the reel to make it convenient for moving, it is an ideal tool for laying cables.








Product Name
Fiberglass Duct Rodder
Material
Epoxy fiber glass(inner core) and imported ABS (out layer)

 Parameter





Frame dimension 1300mm×450mm×1330mm,1200mm×420mm×1220mm,980mm×350mm×1000mm,
680mm×240mm×700mm,
420mm×180mm×400mm.
Reinforcement
E-Glass Fiber
Glass content of inner part
E-Glass Fiber
Density
>1.9g/m3
Diameter tolerance
±0.10mm
Work situation temperature
-40°C ~ +80°C
Min pulling strength
4000N ± 5%
Tensile modulus
>30000 MPa
Consistency of rod
150g ± 5%
Flexural modulus
>30000 MPa
Elongation at Break
2.5-3%






factory show

 If any question about fiberglass snake rod, you can tell me.
We know well about all the process of producing the duct rodder.







Packaging & Shipping



Packaging: Woven bag wrap, Carton box, Tray

You can receive your order items in good conditions.



Our Services



We are a professional supplier of FRP duct rodder in China.

We are shipping to many countries every year.

If there is any purchase need, just contact me.
