frp warning ball aviation obstruction lights warn sphere
Click on the image to view the original image
Product: views:2frp warning ball aviation obstruction lights warn sphere
Branch: LY
Unit Price: Negotiated
Min.Order:
Supply:
Delivery: Shipment within days since the date of payment
Valid until: Long Term
Updated on: 2019-10-16 19:45
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Hebei, China
Brand Name:
LY
Product name:
400mm overhead wire power line aircraft warning ball
Diameter:
400mm,600mm,800mm,900mm
Color:
white,red,orange,white&red
Application:
For aviation
weight:
7kg
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month big capacity of aircraft warning ball
Packaging & Delivery
Packaging Details
packed by carton
Port
Tianjin port
Picture Example:
package-img
Lead Time:
Quantity(Pieces)1 - 300 >300
Est. Time(days)15To be negotiated

frp warning ball aviation obstruction lights warn sphere

Aviation obstruction marking sphere is designed to provide daytime visual warning or nighttime visual warning if comes with reflective tape, for electricity transmission line and overhead wire for aircraft pilots, especially cross river high voltage transmission lines. LANYU  power line marker ball adopts high-grade Fiberglass Reinforced Plastics (FRP), diameter 600mm,800mm,900mm.Customization acceptable.

 400mm overhead wire power line aircraft warning ball

The color of marking sphere should be aviation orange, white and red. Normally, the marking spheres are placed on the highest line. Where there is more than one line at the highest level, white and red, or white and orange spheres should be displayed alternately. This alternating color scheme provides the most conspicuity against all back ground.

Operation

Visible Distance

1200 meters

Voltage Range

35KV-1000KV

Conductor diameter

6.5-55mm

Mechanical structure

Color

Orange, Red, White, Orange/White, Red/White

Sphere body

FRP(Fiberglass  Reinforced Polyester)

Cable clamp

Aluminum alloy

Bolts/nuts/washers

Stainless steel 304

Diameter

  • 600mm
  • 800mm

Weight

6.9KG/9KG

Thickness

3mm

Drain holes

Yes

Optional

l Preformed Armor Rods

l Reflective Strip

Warranty

2 Years


High-rise Power transmission Lines
High slung Cable-car lines
Ropeway cables
Guy Wires

 400mm overhead wire power line aircraft warning ball

• Fiberglass Reinforced Polymer durable material with better weather resistant

• Super corrosion resistant character, stainless steel bolts and nuts

• Aluminum alloy cable clamp guarantees good corrosion resistance

• Various size of cable clamps are available to fit for customers’ cable conductor

• Drain holes structure can prevent accumulated rain water inside the spheres

• Stacking compatible design, save storage space and freight charge

• Optional Preformed Armor Rods provide better protection against vibration and abrasion

• Optional Reflective tape is more durable and economical solution for night visibility

• Both sphere diameters of 600mm and 800mm are available

Installation procedure of Power line markers:
1) At the mount point on the alerting ball, wrap cable protecting bars round cables for 1000-1200mm long, with two ends of protecting bars extending 200-300mm beyond the surface of the ball, as shown in Figure 1.
2) Fix the plastic wires which are mounted on lower hemisphere of the ball onto the cables and twist them, as shown in Figure 2.
3) Combine the lower hemisphere with the upper hemisphere according to module codes. Turn the hemisphere during the assembly and make sure two hemispheres are joined into position .
4) Insert stainless steel bolts(M12*35) and then put flat washers and spring washers around each bolt. Tighten each nut at last, as shown in Figure 4.
