- Place of Origin:
- Hebei, China
- Brand Name:
- Lanyu
- Model Number:
- LYPR01
- Plastic Modling Type:
- Injection
- Item:
- Efficient Plastic Pall Ring Tri Pak Scrubber Packing Media
- Material:
- PP.PE.PVC.CPVC.PVDF
- Size:
- 16mm, 25mm, 38mm, 50mm, 76mm
- Packaging:
- Exported plastic bag
- Sample:
- Free sample
- MOQ:
- 1 cubic meter of Scrubber Packing Media
- Quality:
- 100% new material
- Warranty:
- 1year
- Surface treatment:
- smooth
- Supply Ability:
- 300 Cubic Meter/Cubic Meters per Month big capacity of Scrubber Packing Media
- Packaging Details
- Scrubber Packing Media are always packed in ton bags or plastic bags.
If you need, we can also pack plastic pall ring as your requirement.
- Port
- Shanghai
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Cubic Meters) 1 - 28 29 - 65 >65 Est. Time(days) 7 10 To be negotiated
Efficient Plastic Pall Ring Tri Pak Scrubber Packing Media
Plastic pall ring is made from heat resistant and chemical corrosion resistant plastic , for instance. polypropylene (PP). An advance on the Raschig Ring, the Pall Ring has similar cylindrical dimensions but has two rows of punched out holes, with fingers or webs turned into the centre of the cylinder, which significantly increases the performance of the packing, in terms of throughput, efficiency and pressure drop.
Pall Ring Features:
1. Higher capacity and lower pressure drop than ceramic packing.
2. Multiple sizes provide ability to optimize capacity and efficiency based on application requirements.
3. Relatively high liquid hold-up allows good absorption efficiency with slow chemical reaction. 4. Lower sensitivity to liquid and vapor distribution quality allows use with conventional liquid distributors.
5. Ring and spoke construction provides high mechanical strength, which allows use in deep beds.
Technical Data
| Plastic Pall Ring | |||||
| Material | PE,PP,RPP,PVC,CPVC,PVDF,PTFE | ||||
| Size | 16mm,25mm,38mm,50mm,76mm,80mm,90mm,100mm | ||||
| Color | Transparent, or customized | ||||
| Application | Adsorption, Scrubbing, Separation, Plastic Packed Columns, ect. | ||||
| Item | Size D*H*T(mm) | Number per m³ | Surface Area m²/m³ | Free Volume % | F factor m-1 |
| Dg16 | 16x16x1.0 | 180000 | 274 | 90 | 376 |
| Dg25 | 25x25x1.0 | 53500 | 213 | 91 | 285 |
| Dg38 | 38x38x1.2 | 15800 | 151 | 91 | 200 |
| Dg50 | 50x50x1.5 | 6500 | 100 | 91.5 | 130 |
| Dg76 | 76x76x2.6 | 1930 | 72 | 92 | 9 |
We can supply different types of tower packing medias:
Tower packing medias packaging:
Welcome your inquiry anytime.
