- Place of Origin:
- Hebei, China
- Brand Name:
- Lanyu
- Model Number:
- LYDR01
- Application:
- cable pulling tool
- Surface Treatment:
- ABS coasted
- Technique:
- pultruded
- Item:
- fiberglass push pull duct rod wholesale duct rodder
- Material:
- FRP+ABS
- Diameter:
- 4 - 18mm
- Length:
- 30m-500m (OEM)
- Color:
- yellow, black, blue, white, green
- Accessories:
- frame, wheel, copper connectors
- Marker:
- Meter marker
- MOQ:
- 1 set of wholesale duct rodder
- Working temperature:
- -40~80 degree
- Breaking tension:
- 4.5T
- Supply Ability:
- 2880 Set/Sets per Month quick delivery of wholesale duct rodder
- Packaging Details
- fiberglass push pull duct rod is packed in woven bag wrap, carton box or tray
- Port
- Tianjin, Shanghai
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Sets) 1 - 2 3 - 200 >200 Est. Time(days) 7 15 To be negotiated
fiberglass push pull duct rod wholesale duct rodder
Fiberglass duct rodder is selected as a special tool for pulling electric cables and optical fiber cables in telecom, power industries, buildings and many other fields. The rod is made of fiberglass and high strength resin at high temperature, it is coated by high density polyethylene engineering plastic as its protected layer, which makes the duct rodder cover sliding on surface, durable, corrosion resistant and has good insulation performance, these make it safe for using in cable occupied duct. Along with pull head and handcart, it features easy to move and operate. The fiberglass duct rodder wil be equipped with different size of reels in accordance with the length of the rod, there are wheels on the reel to make it convenient for moving, it is an ideal tool for laying cables.
traceable duct rodder 200m fiber snake duct rodder | ||||||
Material | Epoxy fiber glass(inner core) and imported ABS(out layer) | |||||
Parameter Frame Dimension 1300mm*450mm*1330mm 1200mm*420mm*1220mm 980mm*350mm*1000mm 680mm*240mm*700mm 420mm*180mm*400mm | Reinforcement | E-Glass Fiber | ||||
Glass content of inner part | E-Glass Fiber | |||||
Density | >1.9g/m3 | |||||
Diameter tolerance | +/- 0.1mm | |||||
Work situation temperature | - 40℃ ~ +80℃ | |||||
Min pulling strength | 4000N +/-5% | |||||
Tensile modulus | >3000MPa | |||||
Consistency of rod | 150g+/-5% | |||||
Flexural modulus | >3000MPa | |||||
Elongation at Break | 2.5 - 3% | |||||
fiberglass push pull duct rod wholesale duct rodder
