Click on the image to view the original image
- Brand Name:
- BIOBASE
- Model Number:
- BK-2478
- Place of Origin:
- Shandong, China
- Instrument classification:
- Class II
- Model:
- BK-2478
- Specimen HorizontalStroke:
- 28mm
- Mini. Sectioning Thickness:
- 0.25μm
- Max. Specimen Size:
- 50*70mm
- Feed Speed:
- 450μm/s
- Power Supply:
- AC110/220V±10%, 50/60Hz
- Gross Weight:
- 45kg
- Consumption:
- 100W
- External Size(W*D*H):
- 585*410*305mm
- Package Size(W*D*H):
- 670*550*480mm
- Supply Ability:
- 520 Unit/Units per Month
- Packaging Details
- Wooden case
- Port
- qingdao,tianjin,shanghai
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Units) 1 - 1 >1 Est. Time(days) 10 To be negotiated
BIOBASE Automatic and Semi-automatic Microtome with Streamlined Design
This machine uses a streamlined design, with advanced features, stable and reliable performance and ease of use
Features:
* Large-volume removable waste tray on the top of housing, convenient to use.
* Imported cross-roller guide rails andhigh-precision screw motion mechanism.
* Fast switching between paraffin block clamp and cassette clamp.
* Hand-wheel balance can be precisely adjustedand can be locked at any position,ensuring safetyand convenience of sectioning.
* Blade holder can be laterally movedwithout direct contact,enabling use of the entire length of the blade. (three different segments)
* The red bar on the blade holder covers the whole length of blade to protect the user and enables easy change of the blade.
* Automatic sectioning speed is adjustable. (BK-2498only)
* Auto slicing controller ensures trimming and slicing switching easily; When it is off, semi-auto slicing or trimming is available.(BK-2498only)
* Safety and emergency braking systems (BK-2498 only),security alarm systems, driver-overload protection and auto-sleep protection system.(For all 3 models)
* Control system with 3 modes: conventional mode, intelligence sensing mode and whole layer cutting mode.(BK-2488 only)
Technical Parameters
Model | BK-2478 | BK-2488 | BK-2498 | |
Mode | Semi-automatic without intelligent sensing | Semi-automatic with intelligent sensing | Automatic or Manual Mode without intelligent sensing | |
Function | Sectioning, trimming, fast forward, fast backward, quick conversion; automatic retraction (exceptBK-2478). | |||
Retraction Range | / | 0~50μm ( If 0 is set, retraction function is off ) | ||
Display | LCD Display: | OLED Display: | LED display: | |
Sectioning Thickness Range | 0~60μm | 0.25~100μm
| ||
Trimming Thickness Range | 0 ~60, 0~100, 1~900μm | 1~600μm
| ||
Whole Layer Clearance Distance(Only for BK-2488) | 10~6000μm | |||
Specimen HorizontalStroke | 28mm | |||
Specimen Vertical Stroke | 52 mm | 70mm | ||
Specimen Orientation | XY – 8°, rotation 360° | XY – 8°, rotation ±90° | ||
Mini. Sectioning Thickness | 0.25μm | |||
Max. Specimen Size | 50*70mm | 70*70mm | ||
Feed Speed | 450μm/s | 1500μm/s,3500μm/s | ||
Precision | ±5% | |||
Standard Accessory | Cassette Clamp or Paraffin Block Clamp(Paraffin BlockClamp is acquiescent) | |||
Consumption | 100W | 150W | ||
Power Supply | AC110/220V±10%, 50/60Hz | |||
External Size(W*D*H) | 585*410*305mm | 575*420*330mm | 580*475*340mm | |
Package Size(W*D*H) | 670*550*480mm | 670*550*480mm | 680*570*500mm | |
Gross Weight | 45kg | 45kg | 60kg | |
BIOBASE CHINA
Founded in 1999, having over 2000 employees (till August, 2018), BIOBASE Group is a new high-tech enterprise focusing on development, production and management of scientific equipment, In Vitro Diagnosis (IVD) instrument and reagent.
BIOBASE Group is specialized in products of 8 areas including medical diagnosis, biosafety protection, disinfection and sterilization, water purification system, infant care products, cold chain products, software products, clean room project.BIOBASE Group has certificates including ISO9001, ISO13485, ISO 14001, SGS, CE, NSF, EN, FDA, etc.
BIOBASE Group always adheres to the mission of “service for health for the future” and promotes company’s culture vigorously. Providing with high quality products and good service, BIOBASE would like to establish win-win business cooperation with distributors all over the world.
1. Packages conform to international standards.
2. Forwarders are reliable
3. Deliver the goods timely and safely.
1.Why choose us?
Best price and the best quality! And we have a very professional sales team which can offer you the most professional service.
2. How do you make our business long-term and good relationship?
We will sustaining provide good quality products and good price to all customer, to help user enjoy clean air, and help partners enlarge your market, and get more profit. We provideAgent price to long term partner, welcome to inquiry.
3.How about BIOBASE delivery time?
Within 3-15 workdays after receiving deposit.
4.What is the shipping port?
FOB to Qingdao Port,China(also can ship according to customers’ request)
