High Quality Shaking Incubator
Shaking Incubator Features
* Soft shaking mode, stable and reliable operation.
* Audio and visual alarm for over-temperature, PID contller.
* Adopting unique design to ensure the tank cover can open and close steadily.
* With the function of memory and recovery, avoid the cumbersome operation.
* Large LCD Display with back light can display both the setting parameters and the measured parameters
* Big toughened glass window, can observe the working condition completely.
* Accessories: UV lamp(Standard accessories), humidity controller, inlet air pipe, light system(Optional accessories).
Model | BJPX-103B | BJPX-100B | BJPX-200B | ||
Controller | PID | ||||
Display | LCD | ||||
CirculationMode | Forced convection | ||||
ShakingMode | Rotary shaking | ||||
DriveMode | Unishaft drive | ||||
Temp. Range | RT+5℃~60℃ | 4℃~60℃ | |||
Temp.Accuracy | ±0.1℃ | ||||
Temp.Uniformity | ±0.25℃ | ||||
Rotating Speed | 30~400 rpm | ||||
Rotating Accuracy | ±1rpm | ||||
Vibration Range | Φ25mm | ||||
Refrigerant | / | CFC-Free, R134a | |||
Cooling Consumption | / | 118W | |||
Heating Consumption | 150W | 400W | |||
Timing Range | 0~500 hours | ||||
ShakingPlate Size | 260*260 mm | 400*370mm | 420*400 mm | ||
Standard Capacity | Universal spring clamp | 50ml*4, 100ml*4 250ml*3 500ml*3 | 50ml*5 100ml*5 250ml*4 500ml*3 | ||
Max. Capacity | 100ml*9 or 50ml*9 or 250ml*5 | 50ml*16 or 100ml*16 or 250ml*12 or 500ml*9 or 1000ml*5 | 50ml*25 or 100ml*25 or 250ml*16 or 500ml*9 or 1000ml*9 or 2000ml*5 | ||
Internal Material | Mirror stainless steel | ||||
External Material | ABS | ||||
SafetyFunction | Audio and visual alarm for over-temperature; Alarm for over-speeds; Independent over-temperature protector; Shutdown protection for door opening; Leakage or over-current protection. | ||||
Consumption | 280W | 490W | 580W | ||
Power Supply | AC110V/220V±10%,50/60HZ | ||||
Internal Size(W*D*H)(mm) | 360*340*280 | 410*450*300 | 460*500*350 | ||
External Size(W*D*H)(mm) | 440*420*420 | 610*610*510 | 700*740*560 | ||
Package Size (W*D*H)(mm) | 570*570*590 | 710*710*660 | 800*840*710 | ||
Gross Weight(kg) | 50 | 85 | 120 | ||
