Traditional Box Type Muffle Series
Technical parameters of Muffle Furnace
Model | 2.5-12G | 5-12G | 10-12G | 12-12G |
Dimension of working chamber(mm) | 200*120*80 | 300*200*120 | 400*250*160 | 500*300*200 |
Rated Temperature | 1200°C | |||
Temperature fluctuation | ±1°C | |||
Rated Power (KW) | 2.5 | 5 | 10 | 12 |
Voltage(50HZ) | Singal-phase AC -220V | Singal-phase AC -220V/380 | Triphase AC-380V | Triphase AC-380V |
External dimension(mm) | 480*400*570 | 590*520*620 | 730*570*720 | 770*880*560 |
Model | 2.5-10G | 4-10G | 8-10G | 10-10G | 12-10G |
Dimension of working chamber(mm) | 200*120*80 | 300*200*120 | 400*250*160 | 300*200*300 | 500*300*200 |
Rated Temperature | 1000°C | ||||
Temperature fluctuation | ±1°C | ||||
Rated Power (KW) | 2.5 | 4 | 8 | 10 | 12 |
Voltage(50HZ) | Singal-phase AC -220V | Singal-phase AC -220V | Triphase AC-380V | Triphase AC-380V | Triphase AC-380V |
External dimension(mm) | 480*400*570 | 590*520*620 | 730*570*720 | 550*770*550 | 770*880*560 |
