Medical Laboratory Equipment Medical Elisa Analyzer Elisa processor
Biobase1000A fully automated ELISA analyzer is a 2 micro-plate fully automated processor able to operate the dispense, incubation, reading, data processing and storage of results.
Its user friendly approach for both software and hard ware allows the operator to start working with the instrument as soon as it is out of the box, no pre-adjustments or calibrations required.
Model | Biobase1000A |
Type | Fully automated ELISA analyzer |
Sample racks | 60 or 80 – 12 mm sample tubes or 40 - 16 mm sample tubes |
Dilution rack | 92 positions |
Reagents holder | modular racks to hold calibrators, controls and reagents for 8 methods on line |
Liquid reservoirs | external tanks equipped with level sensors; 2 washing buffer |
Microtiter plates | 2 plates (96 wells) with incubation capability, from room temperature to 45 °C |
Dispensing system | 1 aspirating-dispensing probe with X-Y-Z movement; dilution system with a syringe of 1000 μl, continuous flow washing station |
Washing system | two 8 nozzle on line manifolds with automatic adaptation for the different micro-plates height |
Washing Residual volume | < 3μl |
Washing inaccuracy | CV < 5 % with 300 μl |
Readingsystem | 8 independent photometric channels for mono and bichromatic reading |
Optical filters | 2 filters (450 and 630 nm); 2 more on request (max 4 filters) |
Readinginaccuracy | ± 1% from 0.000 to 1.500 OD ± 2% from 1.500 to 3.000 OD |
Dispensation | from 8 ml to 1000 ml with 1μl resolution; inaccuracy ±1% with 100 μl |
Software | Windows 98 and XP operating system, to set up the work list, patient reports and results filing; calibration curves storage for each carried-out test |
Connection | LIS interface capability, work list set up from Host computer. Capability of connecting more instruments to a single PC. |
Power Supply | 200/110 VAC, 50-60 Hz |
Dimension | 620 x 820 x 720 |
Weight | 80 Kg |
OPTIONAL: | Sample Bar Code Reader |
Mainly packed by Carton box or other common security package, you also can give us your special requirments about it. We will try our best to make sure the goods arrive safely.
BIOBASE GROUP
Established in 1999
Leading professional manufacturer of laboratory and medical products with high quality and competitive price,
Specializing in:
*air protection products
*cold chain products
*analytical instruments
*most of lab and medical products
*laboratory furniture,laboratory and clean room construction
1200employees in China and abroad offices,
Our mission is to
enable our customers to make the world healthier,cleanerand safer.
Add: NO.51 South Gongye Road,Jinan250101,Shandong,China.
Website: www.biobase.cc www.meihuatrade.com www.labproject.cn
Please contact me with the information below to get more details:
Contact: Ray Liu
