BIOBASE LCD Display PC Control Rotary Evaporator with 100ml~2L Collecting Bottle

Click on the image to view the original image

Product：	views：3BIOBASE LCD Display PC Control Rotary Evaporator with 100ml~2L Collecting Bottle
Branch：	BIOBASE
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-12-03 18:40

Product Details

Overview

Quick Details

Condition:: New

Application:: Distillation

Power Source:: Electric

Process:: Rotary

Place of Origin:: Shandong, China

Brand Name:: BIOBASE

Voltage:: /

Power(W):: /

Dimension(L*W*H):: 420*100*580mm

Weight:: /

Certification:: CE ISO

Warranty:: One Year

Speed Range(rpm):: 20-280

Display:: LCD

Heating Temperature Range(℃):: RT-180

RS 232 Interface:: Yes

After-sales Service Provided:: Engineers available to service machinery overseas

Supply Ability

Supply Ability:: 500 Unit/Units per Month

Packaging & Delivery

Packaging Details: Wooden case/ carton

Port: Qingdao/Shanghai/Gunagdong

BIOBASE Laboratory 1L Automatic LCD digital Rotary Evaporator RE100-Pro

Product Description

1.Easy to read large digital LCD screen displays heating temperature ,

Rotation speed and timing

2.Large 5L water-oil heating bath with heating temperature range of RT to 180℃

3.Speed range from 20 to 280 rpm

4.Heating bath with precise temperature control and adjustable safety circuit

5.Designed a detachable operating panel allows remote control

6.Patented condenser (cooling surface 1500 cm2) with excellent cooling effect

7.Motorized lift with quick-action,automatic release evaporating flask to top position in case of power failure

8.Adjustable final position recognition to protect operator and sample against breakage

9.Evaporating flask with an ejector,convenient to remove

10.Available with timer function to precise control processing

11.Chemical-resistant double PTFE system and patented pressure spring provide excellent sealing

12.PC can control and document all parameters via RS232 interface (USB)

The standard collecting bottle is 1L. 100ml/250ml/500ml/2L collecting bottles are also available can can be ordered separately.

Technical Parameters

Technical Parameters:

Rotary Bottle	1L
Collecting Bottle	1L
Display	LCD
Rotating Speed	20-280 rpm
Temperature Range	RT-180℃
Temperature Control Accuracy	±1℃
Lift	Motor
Stroke Height	150mm
Timing Range	1-999 min
Power	1400 W
Motor	DC brushless motor
Rotation	Reversible Direction
External Size (DWH)	457465583 mm
Net Weight	15 kg
Interface	RS 232
Power Supply	110/220V,50/60Hz
Gross weight	40Kg
Packing size	1106065mm
Standard Accessory	1L Rotary bottle1, 1L Collecting bottle1,
Optional Accessory	Vacuum pump, Recirculating chiller
