1. Exterior material: Cold-rolled steel with electrostatic coating.
2. Stainless steel inner chamber;
Features:
1. Exterior material: Cold-rolled steel with electrostatic coating.
2. Stainless steel inner chamber;
3. PID micro-computer intelligent temperature controller, over-temperature protection; LED display;
4. Double-layer glass observation window, adjustable airtight buckle lock.
5.Differences with drying oven:
There is fan inside,don"t have air circulation,fully sealed inside,temperature rise is very fast.
FE Function type has the following feature other than the above function:
1. Adjustable speed fan
2. Large LCD display screen shows the multiple data; has timing function and over temperature protection.
3.Independent temperature limit alarm system.; Auto alarm for heating suspend.
4. Optional RS-485 interface for software connection.
Note: model HAS-F230 has no function of speed adjustment.
Standard Accessory: adjustablle shelves
Model |
HAS-30F HAS-30FE
| HAS-45F HAS-45FE | HAS-65F HAS-65FE |
HAS-125F HAS-125FE |
HAS-230F HAS-230FE |
Voltage | 220V/50Hz | ||||
Tem. Range(℃) | RT+5~300℃ | ||||
Tem. Motion(℃) | ±1℃ | ||||
Tem. Resolution Ratio(℃) | 0.1℃ | ||||
Ambient tem.(℃) | 5-40℃ | ||||
Heating power(w) | 0.8 | 1 | 1.6 | 1.2 | 3 |
Inner Champer Size (mm) | 310×310×310 | 350×350×350 | 400×360×450 | 500×450×550 | 500×450×550 |
Exterior Size (mm) | 400×510×695 | 500×550×735 | 550×550×840 | 636×680×915 | 636×680×915 |
Packing Size (mm) | 610×540×830 | 660×590×870 | 670×640×970 | 760×750×1070 | 900×800×1350 |
Load per rack(Kg) | 15/kg 2 for standard configuration | ||||
N.W.(Kg) | 39 | 42 | 48 | 58 | 70 |
G.W.(Kg) | 52 | 55 | 61 | 73 | 115 |
Timing range | 1-9999min | ||||
