automatic biochemistry analyzer / clinical chemistry analyzer / mindray chemistry analyzer

Click on the image to view the original image

Product：	views：3automatic biochemistry analyzer / clinical chemistry analyzer / mindray chemistry analyzer
Branch：	BIOBASE
Type：	Biochemical Analysis System
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-12-03 18:40

Product Details

Overview

Quick Details

Type:: Biochemical Analysis System

Brand Name:: BIOBASE

Model Number:: BK-400(CRYSTAL)

Place of Origin:: Shandong, China

Instrument classification:: Class I

Size:: 1020(W)mm*830(D)mm*1200(H)mm

Name:: fully automatic biochemistry analyzer

Methodology:: End-point,Fixed-time,Kinetic,Turbidimetry

Wavelength:: 340,405,450,510,546,578,630,700

Sample tray:: 60 positions(including QC and calibration

Reagent tray:: 45 positions for both R1 and R2

Reaction cuvette:: 120 hard glass cuvettes

Lignt source:: halogen lamp 12V,20W

Temperature control:: 37℃ automatic thermostat

Supply Ability

Supply Ability:: 100 Set/Sets per Month

Packaging & Delivery

Packaging Details: packed in big wooden case carefully with whole polyfoam protection and moistureproof hood to prevent any shipping damage .

Port: Qingdao

Product Description

Biobase-Crystal is fully automatic,discrete,random access biochemistry analyzer.It is eupipped with:60 sample position,45 reagent position,and 120 reaction cuvettes.It is 300 test per hour,with both CE & FDA certified.

1.Sample unit:
Sample Settings: 60 sample positions, including calibration, quality control and emergency,
primary tubes and serum is available.
Sample Volume: 2ul ~50ul (0.1ul stepping).

2.Reagent unit:
Reagent Position: R1 45 & R2 45,total 90 refrigerated reagent position.
Reagent Volume: R1:25~300ul, R2:10~150ul (1ul stepping), supporting reagent of different brand
Temperature Control: continuous cooling system working within 24 hours.

3. Reaction unit:

Cuvettes: 120 independent reaction cuvettes (optical path length 6mm)
Cleaning: automatic water cleaning and drying system.
Temperature Control: 37C±0.1C.

Technical Parameter

Fully Automatic biochemistry analyzer

Overall Performance	Model	BK-400(CRYSTAL)
	Type	Discrete, fully automatic
	Throughput	300T/H
	Analysis Method	End-point, Fixed-time,Rate
	Certification	CE, FDA, ISO9001, ISO14001, ISO13485
Sample unit	Sample Settings	60 sample positions, including calibration, quality control and emergency
	Sample Volume	2ul ~70ul (0.1ul stepping)
	Sample Probe	Teflon coating probe, with liquid level sensor, with anti-collision function
	Probe cleaning	Automatic washing both interior and exterior
	Analysis Items	Analyzing maximally 45 items at the same time
Reagent unit	Reagent Position	45 low-temperature refrigerated reagent position
	Reagent Volume	20ul ~350ul (1ul stepping), supporting reagent from different brand
	Temperature Control	Continuous 2℃~8℃ cooling within 24 hours
	Reagent Probe	Teflon coating probe, with liquid level sensor,withanti-collision function.
	Probe cleaning	Automatic washing both interior and exterior
Reaction unit	Temperature Control	37℃±0.1℃, with online software monitor the temperature
	Cuvettes	120 reusable reaction cuvettes (optical path length 6mm)
	Mixer	After injecting reagent and sample, blending immediately
	Washing	Automatic water cleaning and drying system
	System Adjustment	System can record the blank value and get more accurate result by deducting blank base value of each cuvette
Optical System	Light Source	12V/30W halogen-tungsten lamp, 2000 hours
	Receiver	8 precision photo receivers
	Wavelength Range	340, 405, 450, 510, 546, 578, 630, 700mm
	Linear Range	0.000~2.500Abs
Calibration and QC	Calibration	One-point, two-point, multi-point, factor
Calibration and QC	Quality Control	Inserting quality control at random, with reaction curve can check each test items clearly
Software	Emergency Function	Emergency sample can be placed in the sample tray at any time
	Software	Windows 7 /8/10 or above, LIS system available
	Data Processing	Having reaction curve detection and data display function in the whole process
Others	Power Supply	110/220V±10%, 50/60Hz
	External Size(WDH)	1020mm830mm1200mm
	Package Size(WDH)	11689081288mm
	Net/Gross Weight	130kg/185kg
