- High accuracy of temperature control (optimum: ± 0.05℃), high reliability and anti-interference.
- Control and operating parameters (including for detectors) set up by the keyboard. Self-diagnosis system,
- power-fail protection, file storage and call, limited temperature setting. Accurate display of setting and actual
- value of temperature control of each path, bridge current of TCD, sensitivity of FID, retention and analysis
- time.
- Four paths of independent control sections: column oven, sample injector, detector and thermal conductive
- pond.
- 5-ramp programmed temperature rising control. Auto-drop of temperature of column oven (auto-opening
- the door behind the oven) to a fast cooling.
- Dual FID provided with options of GC112 A-TCD, GC 112 A-FPD and GC112A-NPD, gas sampling valve,
- transformation oven, absorber and pyrolysis absorber available for selection. Two detectors can be installed
- at the same time with high sensitivity. Short time to be stabilized and easy to clean and install nozzle.
- Packed column and capillary column (0.53 large diameter or small diameter) can be installed easily including
- a complete set of split sampling connector and tailing connector to be installed free of charge.
- Analysis can be conducted in packed or capillary column with multiple sampling methods.
- Packed column: on-column sampling, instantaneous vaporized sampling and gas sampling.
- Capillary column: split sampling and 0.53mm large diameter capillary direct sampling.
- Construction of dual gas path, dual sample injector and dual packed column system can effectively avoid
- baseline undulation and drift in real time and facilitate programmed temperature rising analysis. Accurate and
- scaled type gas path control valves will provide a high repeatability and stability.
- Advanced functions: auto ON/OFF temperature control system, permanent data storage, file storage and call
- and over-temperature protection.
- Large volume column (300x280x270mm) can hold capillary column and dual packed column. Built-in heating
- filament structure is in favor of quartz capillary analysis.
- A complete set of accessories including purifier, pressure-reducing valve, gas path tube, wrench and tools,
- injection needle and connectors of all kinds are provided free of charge and are ready to connect with
- supply-air system prepared by users.
OPTIONAL ACCESSORIES
- TCD
- FPD
- NPD
- N2000 Software with I/O port
- OVERALL DIMENSION & WEIGHT
- Shipping package dimension: 990x630x690mm
- Net Weight: 50kg
- Gross Weight: 75kg
Mainly packed by Carton box or other common security package, you also can give us your special requirments about it. We will try our best to make sure the goods arrive safely.
At present, we are dealing on laboratory equipment and medical analytical instruments, such as
biological safety cabinet, laminar flow clean bench, fume hood, refrigerator and freezer, incubator, oven, autoclave, freeze dryer, spectrophotometer, centrifuge, Elisa reader and washer, Semi&Auto biochemistry analyzer, biochemistry reagents etc.
BIOBASE is a professional manufacturer of laboratory products from 1999. Our main products are Biosafety Cabinet (Class I/II/III), Laminar Flow Cabinet, Fume Hood, Biochemistry Analyzer, Reagent, Autoclave anf Incubator.
We have more than 800 employees and 2000 square meters production base, our output per year is amount to 10000 units. Pursuing the highst quality is the tenet if BIOBASE. We hope everybody will enjoy BIOBASE service to keep away from the infectious disease.
Our advantages:
-We built an excellent research team which consists of 50 professional engineers
-We have 14 years production experience and a strong technical production team, we adopt high-tech and state-of-the-art production equipments from Italy, Japan and Switzerland, tec.
-We have a strong quality control team to inspect all production stage, from the purchased accesory to the finished products.
-We have full sets of advanced quality assurance equipments
We have ISO9001 quality management system; ISO14001 environmental managemnet system, ISO13485, CE mark, MET and NAF49 certificate.
We got EN12469 certificate for Biosafety Cabinet in 2013.
Please contact me with the information below to get more details:
Contact: Ray Liu
