Vertical Autoclave is mainly used in hospitals, laboratories, universities and other institutes where users need to sterilize temperature-resistance solid and liquid.
For BIOBASE hand wheel type vertical autoclave, there are 5 fixed programs and 2 DIY programs according to different sterilization objects. And there is also program for sterilizing and dissolving culture medium. Users just need to select different programs for sterilization.
1. Complete process of filling water, dynamic pulse exhaust, heating, sterilizing, draining and drying run automatically.
2. LED screen displays all steps of full process as well as error codes.
3. Sterilization programs for dressings, equipment, rubber, culture medium, waste, etc.
4. Adopting certain temperature (98~102℃)exhaust method and dynamic pulse exhaust method to completely empty the cold air inside chamber for ensuring steam saturability.
5. Automatic selecting quick or low exhaust to avoid sterilization liquid overflowing.
6. Inner stainless steel water tank for water and steam to circulate inside. Steam does not exhaust during sterilization, so as to keep the outside clean and dry.
7. Independent knock-down service window, easy for repairing and maintenance.
8. Hand wheel type of quick-open door structure, self-expandable sealing ring, easy operating and safe.
Safety feature:
1. Over pressure, safety valve can automatically open to release pressure.
2. Over temperature, the system will power off automatically.
3. Sensor at door closing position, to check the door status. If door is open, operation will stop.
4. Anti dry-out function. If water level is too low, system will power off and error code displays on screen.
5. Over current, over voltage or electric leakage protection apparatus-air switch.
6. The door is covered with safety shell which is made of thermal insulation material to protect operator from burning by heat and looks nice.
Model | BKQ-B50II | BKQ-B75II | BKQ-B100II |
Capacity | 50L | 75L | 100L |
Chamber material | 304 medical stainless steel | ||
Max designed pressure | 0.28Mpa | ||
Max designed temp | 150℃ | ||
Working pressure | 0.22MPa | ||
Working temp range | 105~136℃ | ||
Temp accuracy | ±0.1℃ | ||
Timing range | 0-999min | ||
Dynamic pulse exhaust times | 0~9 times | ||
Dynamic pulse exhaust temp | 105~132℃ | ||
Dissolution temp range | 60~100℃(programmable) | ||
Temp holding range | 40~60℃(programmable) | ||
Power supply | AC220V,50/60Hz; 22A | ||
Standard Accessories | Stainless steel basket*2pcs | ||
Chamber size | φ386*50mm | φ386*682mm | φ386*875mm |
Power consumption | 4.4KW | 4.7KW | 5.2KW |
Outer size (W*D*H) | 550*640*980mm | 550*640*1080mm | 550*640*1260mm |
Net weight | 70KG | 85KG | 105KG |
Biobase Meihua Trading Co.,Ltd is the subsidiary of BIOBASE group. BIOBASE,
established in 1999,has been through high and stable development for 15 years,is now with revenues of one hundred million,1200employees in China and abroad offices.The products we manufacture extend
to most of the laboratory items and scientific analytical equipment,covering biological safety
cabinets,laminar flow cabinets,fume hoods,incubators,autoclaves,biochemistry analyzers,
ELISA microplate processors drying ovens,centrifuges,microscopes,biochemical reagents, etc.Our mission is to enable our customers to make the world healthier,cleanerand safer.
BIOBASE group invests in science and technology researches,aims to keep improving products
performance and quality as well as develops new products to meet customers"wide requirement.We satisfy our customers by offering comprehensive support,purchase convenience and we are ready to
serve more and more BIOBASE users.
BIOBASE group,serving global distributors and its loyal end users,is becoming one of the most
important scientific services supplier.
We have acquired ISO, CE, EN, NSF and FDA certificates.
Important information that you may concern about:
1. Pacakge: All the products wil be packed firmaly in standard wooden case/ carton to make sure that the product won"t be damaged during the delivery.
2. Delivery time: Generally, the delivery time is about 10-20 days. If the product is a hot-sale one and out of stock, that might be a bit longer but we will try our best to let our customers receive the products as soon as we can.
3. Warranty: The warranty is generally 12-month, during which the replacement of broken components are free. Accessories are available.
4. Payment: T/T in advance is preferred. West union is also accpted.
