BIOBASE Laboratory Fluorescence Microscope Fluorescence Biological Microscope
Model | XY-2 | Note | ||
Viewing Head | Compensation Binocular head inclined at45°, | Compensation Trinocular head inclined at45°, | • | |
° | ||||
Eyepiece | Wide Field WF10X/18 eyepiece | • | ||
P16X eyepiece | • | |||
Nosepiece | Backward Quadruple Nosepiece | • | ||
Backward Quintuple Nosepiece | ° | |||
Objectives | Achromatic Objective 10X, 20X, 40X(S), 100X (S, oil) | • | ||
Semi- Plan Achromatic Objective 10X, 20X, 40X(S), 100X (S, oil) | ° | |||
Plan Achromatic Objective 10X, 20X, 40X(S), 100X (S, oil) | ° | |||
Infinite Plan Achromatic Objective 10X, 20X, 40X(S), 100X (S, oil) | ° | |||
Stage | Double Layers Mechanical Stage:140X140, Moving range:75X50mm | • | ||
Condenser | Abbe Condenser N.A.=1.25 With Iris Diaphragm and Filters | • | ||
Focusing System | Coaxial Coarse & Fine Adjustment, Fine Division 0.002mm, Moving range:24mm | • | ||
Collector | High Brightness Collector | • | ||
Kohler Illumination with Iris Diaphragm | ° | |||
Illumination | AC220V/110V, 6V20W, Halogen Lamp, Brightness Adjustable. | • | ||
AC220V/110V, Super Light LED Lamp, Brightness Adjustable. | ° | |||
Filters | Green and Blue Filters | ° | ||
Fluorescent Attachment: | ||||
Fluorescent Illumination | B(Blue), G(Green) Exciting Light Filter System, O ordinary Light System | • | ||
U(Ultraviolet), V(Violet) Exciting Light Filter System, O ordinary Light System | ° | |||
Illumination | 100W Ultra Hi-Voltage Spherical Mercury Lamp | • | ||
Protect Barrier | Barrier to Resist the Ultra Violet Light | • | ||
Power Supplier | Power Supplier AC110/220V, Digital Display and Timer | • | ||
Fluorescent Free Objective | 10X 20X 40X 100X | • | ||
Optional Parts | High resolution COMS Digital Camera 5.0MP, 9.0MP with software | |||
-We built an excellent research team which consists of 50 professional engineers
-We have 13 years production experience and a strong technical production team, we adopt hih-tech and state-of art production equipments from Italy, Japan, and Switzerland, etc.
-We have a strong quality control team to inspect all production stage, from the purchased accessory to the finished products.
-We have full sets of advanced quality assurance equipments.
-Certificates: ISO9001;ISO13485;ISO14001; CE; MET; NSF 49.
-We are and will continue to be supplier of the most categaries of laboratory.
Founded in 1999, BIOBASE is a world leading high-tech enterprise focusing on Research & Development, manufacturing and management of laboratory and pharmaceutical equipment. Products have served for clients in more than 100 nations.
BIOBASE provides more than 150 different types of product, including Fully Automated Biochemistry Analyzers, Automated Elisa Processors, Biological Safety Cabinets, Fume Hood, Laminar Flow Cabinet, Autoclaves, Refrigerators, Freezers, Incubators, Water Purifiers and etc. The company has been certified by international standards such as ISO 9001, ISO 13485 and ISO 14001. Various products have obtained international certifications like CE, MET, ETL, and have been registered in FDA, RCM, etc.
With more than 2000 employees and 50000 sqm production base, BIOBASE remains dedicated to deliver innovative solutions for the users with a strong R&D team formed by post-graduates and doctors. The service team is adequately qualified to offer training and service on the installation and maintenance for the full range of products. Engineers are experienced on hands-on design, manufacturing, testing and troubleshooting.
