BS-UV-1200 ultraviolet visible spectrophotometer
Introduction
BS-UV-1200 spectrophotometer is the ideal instrument for education and QC laboratories.
Using your standard sample solutions, you can get a standard curve on the large LCD screen.
They are widely used in colleges and enterprises for general quantitative analysis and experiments.
Features
1 Large LCD screen (128*64 Dots).
2 It can display total 50 groups of data, 3 groups per screen. It also can display standard curve and the curve equation.
3 System can also save the test results. Total 200 groups of data and 200 standard curves can be saved; it is convenient for check and reset.
4 Data can be restored after a sudden power cut.
5 Auto setting wavelength.
6 Tungsten lamp & Deuterium lamp can be turned on/off individually to extend lifetime.
7 Pre-aligned design makes it convenient to change lamps.
8 Large sample compartment, it can accommodate 5-100mm path length cuvettes with optional holders.
A variety of optional accessories are available.
9 The optional application software M. Wave Professional provides complete control of the spectrophotometer through the Built-in USB port. You can achieve the following functions:
I. Quantitative; II. Kinetics; III. Wavelength Scan; IV. Multi Wavelength; V. DNA/Protein.
Specification:
Model | BS-V-1200 | BS-UV-1200 | BS-UV-1100 |
Wavelength Range | 325-1000nm | 200-1000nm | |
Spectral Bandwidth | 4nm (2nm optional) | ||
Optical System | Single Beam, Grating 1200 lines/mm | ||
Wavelength Accuracy | ± 2nm | ||
Wavelength Repeatability | 0.8nm | 1nm | |
Photometric Accuracy | ≤±0.5%T or ±0.003A@1A | ||
Photometric Repeatability | ≤0.2%T | ||
Photometric Range | 0-200%T,-0.3-3A,0-9999Conc. | ||
Stray Light | 0.2%T 220nm, 360nm | 0.2%T 360nm | |
Stability | ±0.002A/h @500nm | ||
Detector | Silicon Photodiode | ||
Standard Cell Holder | 4-position 10nm cell changer | ||
Sample Compartment | Standard 10nm pathlength cuvette | ||
Light Source | Tungsten lamp | Tungsten & Deuterium lamp | |
Output | USB Port & Parallel Port (printer) | ||
Power Requirement | AC110/220V 50/60Hz | ||
Dimensions (W*D*H) | 470*370*180mm | ||
Weight | 12kg | 14kg | |
