Vacuum Vortex Mixer With Aluminium Cast Base
- MX-S with wide speed range of 0-2500rpm, stepless speed regulation
- MX-S used for various mixing applications with optional adapters, handles up to 48 tubes
- Specially designed vacuum suction feet hold to the work surface and prevent the unit from movement
- Aluminium cast base avoids unnecessary “walking”
Microplate mixer
- Wide range of accessories, easy installation and replacement
- Continuous operation
- Stepless speed regulation of motor
- DC brushless motor low running noise and long service
Model | MX-S | MX-E |
Power supply | 110/220V, 50/60Hz | |
Consumption | 60W | |
Shaking movement | Orbital | |
Orbital diameter [mm] | 4 | 4.8 |
Motor rating input [W] | 58 | 12 |
Motor rating output [W] | 10 | 8 |
Speed range [rpm] | 0-2500 | 3000 |
Speed display | Scale | / |
Run type | Continuous/touch operation | Touch oepration |
Dimensions [W*D*H mm] | 127*130*160 | 134*134*70.5 |
Weight [kg] | 3.5 | 0.8 |
Permissible ambient temp. | 5-40℃ | |
Permissible relative humidity | 80% | |
Protection class acc. DIN EN60529 | IP21 | |
Model | MX-M |
Power supply | 110/220V, 50/60Hz |
Consumption | 20W |
Shaking movement | Orbital |
Orbital diameter [mm] | 4.5 |
Max. shaking weight (with attachments) [kg] | 0.5 |
Motor type | External rotor brushless motor |
Motor rating input [W] | 18 |
Motor rating output [W] | 10 |
Speed range [rpm] | 0-1500 |
Speed display | Scale |
Dimensions [mm] | 260*150*80 |
Weight [kg] | 3 |
Permissible ambient temperature [℃] | 5-40 |
Permissible relative humidity | 80% |
Protection class acc. to DIN EN60529 | IP21 |
Mainly packed by Carton box or other common security package, you also can give us your special requirments about it. We will try our best to make sure the goods arrive safely.
