| Model | RE-1002 | RE-2002 | RE-5003 |
| Shelf Material | Coating anti-corrosive Pot shell material :Coating anti-corrosive 250*365*150mm | ||
| Pot shell material(mm) | Coating Anti-corrosive710*620*700 | Coating anti-corrosive630*534*638 | Coating anti-corrosive490*430*540 |
| Pot material(mm) | Stainless steel 550*320 | Stainless steel 450*250 | Stainless steel 350*220 |
| Plate size(mm) | 534*504 | 474*474 | 550*320 |
| Rotary Bottle(L) | 20Ø95flange diameter | ||
| Receiving Flask(L) | 10Ø95flange diameter | ||
| Collecting Bottle(L) | 0.5 24#standard size | ||
| Vacuum(Mpa) | -0.098 | ||
| Rotary Power | 120W | 180W | |
| Rotary Speed(r/min) | 0-110 | ||
| Evaporating Rate(L/H2O) | ≥6 | ≥10 | ≥18 |
| Heating power | 3KW | 5KW | 8KW |
| 380V/50Hz | |||
| Bath temperature control range | 0-400℃ | ||
| Temperature control accuracy | ±1℃ | ||
| Motor Power(w) | 120 | 120 | 180 |
| Bath Power(kw) | 3 | 5 | 7or8 |
| Lifting distance | 180mm | ||
| Voltage/Frequency(V/Hz) | 220V/50Hz | ||
| External Size(mm) | 970*480*1950 | 1170*540*2200 | 1520*620*2470 |
| Packing Size(mm) | 1350*350*400 or1280*570*660 0.67m3 | 1370*700*680 or 700*680*740 1m3 | 1450*390*440or1150*840*660 1.34m3 |
| Packing Weight(KG) | 100 | 123 | 170 |
| Speed adjustable mode | Frequency control of motor speed | ||
| Rotate speed display mode | Digital display | ||
| Temperature display mode | K Sensors,Digital display | ||
| Temperature control mode | Intelligent control | ||
| Sealing way | Four fluorine components seal | ||
| Lift way | host lift by manual | ||
| Condenser | Vertical efficiency three reflow condenser | ||
| Main condenser | |||
| 120*640 | |||
| Deputy cold | |||
| 135*470 | |||
| Continuous charging | Check valve control | ||
| Vacuum display mode | By Vacuum form | ||
| Anti-explosion | Anti-explosion inverter, Anti-explosion motor EX180W | ||
| Framework | Plastic or PTFE | ||
| Lifting mode | automatically | ||
| Collecting device | Double collect bottles | ||
| Bath pot material | 304 stainless steel | ||
Mainly packed by Carton box or other common security package, you also can give us your special requirments about it. We will try our best to make sure the goods arrive safely.
