- Applicable Industries:
- lab
- Application:
- Medicine Processing, Chemicals Processing
- Condition:
- New
- Type:
- Freeze Drying Equipment
- Place of Origin:
- Shandong, China
- Brand Name:
- BIOBASE
- Voltage:
- 220
- Power(W):
- As per requirement
- Dimension(L*W*H):
- 582*625*530
- Weight:
- depend on the detail model
- Certification:
- ISO, CE
- Warranty:
- 12 month
- After-sales Service Provided:
- Online support, Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Engineers available to service machinery overseas
- Key Selling Points:
- High Safety Level
- Freeze Drying Area(m2):
- 0.075
- Ice Condenser Temp(℃):
- -50 or -80
- Vacuum Degree(Pa):
- <10
- Water Capture Capacity(Kg/24h):
- 3
- Material Loading Capacity(ml):
- 750
- Material Loading Capacity/shelf(ml):
- 250
- Tray specification:
- 180*20
- Quantity of Tray:
- 3
- Supply Ability:
- 5000 Unit/Units per Year
- Packaging Details
- wooden box
- Port
- qingdao
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Units) 1 - 1 >1 Est. Time(days) 24 To be negotiated
Vacuum Lyophilizer , Freeze Dryer for Laboratory or food
Freeze Dryer-Table Top Type
1. The 7 inch LCD display panel.
2. Cascade refrigeration technology.
3. With historical data inquiry function.
4. Drying cabinet is transparent which is visual and safe.
5. Large capacity Ice condenser trap and without coil inside.
6. The machine is equipped with USB interface on control panel.
7. Ice condenser trap and operation panel are made by stainless steel.
8. The pre-freeze shelf can be used as guide barrel to speed up the drying rate.
Model | BK-FD10S | BK-FD10T | BK-FD10P | BK-FD10PT | |||
Type | Standard chamber | Stoppering chamber | Standard chamber with 8 port manifold | Standard stoppering with 8 port manifold | |||
Final Condenser Temp (℃) | ≤-56 | ≤-56 | ≤-56 | ≤-56 | |||
Vacuum Degree (Pa) | <10 | <10 | <10 | <10 | |||
Freeze Drying Area (m2) | 0.12 | 0.09 | 0.12 | 0.09 | |||
Ice Condenser Capacity (Kg/24h) | 3 | 3 | 3 | 3 | |||
Shelves | 4 | 3 | 4 | 3 | |||
Material Loading Capacity/Shelf (ml) | 300 | 300 | 300 | 300 | |||
Material Loading Capacity (ml) | 1200 | 900 | 1200 | 900 | |||
Freeze Drying Time (H) | 24 | 24 | 24 | 24 | |||
Manifold | / | / | 8 pieces | 8 pieces | |||
USB Interface | Yes | Yes | Yes | Yes | |||
Drying Chamber (Standard) | Transparent acrylic | ||||||
Vacuum Pump (Standard) | Model: 2XZ-2, Speed: 2L/s (China-Made) | ||||||
Control System | Microprocessor, touch screen | ||||||
Power Supply | AC220V±10%,50/60Hz | ||||||
External Size (W*D*H) | 580*625*530/960mm | ||||||
Package Size | Main Body | 670*660*610mm | |||||
Drying Chamber | 350*350*570mm | ||||||
Vacuum Pump | 570*370*190mm | ||||||
Gross Weight | 105kg | 110kg | 110kg | 110kg | |||
Note | Shelf(plate) heating and cold trap(ice condenser) defrosting function are optional; The vacuum pump, standard drying chamber and all other accessories,like valve, flask etc. are standard accessories; The vacuum pump is independently packed in a separate package. | ||||||
Freeze Dryer Accessories
Founded in 1999, BIOBASE is a world leading high-tech enterprise focusing on Research & Development, manufacturing and management of laboratory and pharmaceutical equipment. Products have served for clients in more than 100 nations.
BIOBASE provides more than 150 different types of product, including Fully Automated Biochemistry Analyzers, Automated Elisa Processors, Biological Safety Cabinets, Fume Hood, Laminar Flow Cabinet, Autoclaves, Refrigerators, Freezers, Incubators, Water Purifiers and etc. The company has been certified by international standards such as ISO 9001, ISO 13485 and ISO 14001. Various products have obtained international certifications like CE, MET, ETL, and have been registered in FDA, RCM, etc.
With more than 2000 employees and 50000 sqm production base, BIOBASE remains dedicated to deliver innovative solutions for the users with a strong R&D team formed by post-graduates and doctors. The service team is adequately qualified to offer training and service on the installation and maintenance for the full range of products. Engineers are experienced on hands-on design, manufacturing, testing and troubleshooting.
