BIOBASE China Class II A2 Biological Safety Cabinet
Applications of Class II A2 Biological Safety Cabinet:
Three protection: operator, sample and environment.
Airflow system: 70% air recirculation, 30% air exhaust
A2 Cabinet is suitable for working with microbiological research in the absence of volatile or toxic chemicals and radionuclide.
Air Flow Pattern of Class II A2 Biological Safety Cabinet:
Features of Class II A2 Biological Safety Cabinet:
Technical Parameters of Class II A2 Biological Safety Cabinet:
Model | BSC-1100IIA2-X | BSC-1300IIA2-X | BSC-1500IIA2-X | BSC-1800IIA2-X | BSC-2000IIA2-X | |
Internal Size (W*D*H) | 940* 600*660 mm | 1150*600*660 mm | 1350*600*660mm | 1710*600*660 mm | 1800*600*660mm | |
External Size (W*D*H) | 1100*750*2250mm | 1300*750*2250mm | 1500*750*2250mm | 1870*750*2290mm | 1950*800*2305mm | |
Tested Opening | Safety Height = 200 mm | |||||
Max Opening | 420mm | 420mm | 400mm | 400mm | 400mm | |
Inflow Velocity | 0.53±0.025 m/s | |||||
Downflow Velocity | 0.33±0.025 m/s | |||||
HEPA Filter | Two, 99.999% efficient at 0.3 um. Filter life indicator. | |||||
Front Window | Motorized. Two-layer laminated toughened glass ≥ 5mm. Anti UV. | |||||
Noise | EN12469 ≤ 58 dB / NSF49 ≤ 61 dB | |||||
UV Lamp | 30W*1 | 30W* 1 | 40W* 1 | 40W*2 | 40W* 1 | |
UV timer, UV life indicator, emission of 253.7 nanometers for most efficient decontamination. | ||||||
Lamp | LED Lamp | Fluorescent Lamp | ||||
12W*2 | 14W*2 | 16W*2 | 40W*2 | 40W*2 | ||
Illumination | ≥1000Lux | |||||
Consumption | 760W | 800W | 900W | 900W | 1500W | |
Waterproof Sockets | Two, total load of two sockets: 500W | |||||
Display | LCD display: exhaust filter and downflow filter pressure, filter and UV lamp working time, inflow and downflow velocity, filter life, humidity and temperature, system working time etc. | |||||
Control System | Microprocessor | |||||
Airflow System | 70% air recirculation, 30% air exhaust | |||||
Visual and audio alarm | Filter replacement, window over height, abnormal air flow velocity. | |||||
Material
| Work Zone: 304 stainless steel | |||||
Main Body: Cold-rolled steel with anti-bacteria powder coating. | ||||||
Work Surface Height | 750mm
| |||||
Caster | Footmaster caster | |||||
Power Supply | 110/220V±10%, 60/50Hz | |||||
Standard Accessory | LED lamp,UV lamp*2 ,Base stand, Remote control, Foot switch, Drain valve, Waterproof sockets*2 | Fluorescent lamp, UV lamp*2 ,Base stand, Remote control, Foot switch, Drain valve, Waterproof sockets*2 | ||||
Optional Accessory | Water and gas tap | |||||
Gross Weight | 243kg | 280kg | 316kg | 395kg | 420kg | |
Package Size (W*D*H) | 1220× 1000× 1840 mm | 1460*1050*1800 mm | 1630*1000*1820 mm | 2000*950*1820 mm | 2090*1050*1860 mm | |
Standard Accessory:
Fluorescent lamp 1pc
UV lamp 2pcs
Base stand 1pc
Remote control 1pc
Foot switch 1pc
Drain valve 1pc
Waterproof sockets 2pcs
Optional Accessory:
Water and gas tap
