CE/FDA BK-480 Fully Automatic Biochemistry Analyzer price with Complete After-sales Service
1. Fully automatic, Discrete, Random access
2.400 T/H, 60/90 sample position and 120 reusable cuvettes.
3. 90 refrigerated reagent tray (R1:45 R2:45), 24 hour working.
4. Reversed optics and imported photo sensor, ensuring the precision of detection results.
5. Precision dispense pumps assures the accuracy of adding sample volmue, sample volume step by 0.1μl, reagent volume step by 1μl.
Overall Performance | Model | BK-480(RUBY) |
Type | Vertical,Discrete,Fully automatic | |
Throughput | 400T/H | |
Analysis Method | End-point,kinetic,Two-point | |
Certification | CE, FDA, ISO9001, ISO14001, ISO13485 | |
Sample & Reagent Unit | Sample Positions | 120 sample positions |
Reagent Positions | 90 pcs (With refrigerated function) | |
Sample Volume | 2-30ul,0.1μl step | |
Reagent Volume | 20-300μl,1μl step | |
Sample& Reagent Probe | Automatic liquid level detecting Collision protection function Probe internal/external washing Probe deepth automatic adjustmen | |
Probe cleaning | Automatic washing both interior and exterior | |
Reagent tray cooling | Continuous 2℃~8℃ cooling within 24 hours | |
Reaction Unit | Reaction Time | 10 minutes |
Temperature Control | 37±0.1℃,automatic heating | |
Cuvettes | 90 reusable reaction cuvettes | |
Washing | After finishtesting, washing probe wash cuvettes automatically | |
Optical System | Light Source | Halogen-tungsten lamp |
Wavelength | 340-700nm,8 wavelengths,(4 positions are optional) | |
Absorbance range | 0-4.00Abs | |
Linear Range | 0.0001Abs | |
Calibration and QC | Calibration | Linear/nonlinear,one point,multi-point(Max 8 points) |
Quality Control | QC plot automatically depict the function condition,show the QC results | |
Software | Intelligent software | Automatic washing cuvette when start test&finish test,Automatic detect sample& reagent volume,Reaction temperature detecting when startup |
Alarm | Automatic alarm of no reagent,no sample,wrong run,out of linearity range etc, Automatic re-test sample in next order after no reagent | |
Software | Windows 7,Windows 8 or above, windows XP | |
Others | Power Supply | AC110/220V,±10%, 50/60Hz,1000VA |
Package Size(W*D*H) | 1220*1340*890mm | |
Gross Weight | 200kg |
