Orbital and Linear Shak
- Compact, orbital and Linear shakers with ideal shaking motion, for a maximum shaking weight of 7.5kg and 2.5kg
- LCD displays speed and timer. Speed, timer and operating mode can be viewed simultaneously
- Wide range of platforms for use with a variety of vessels
- Electronic time switching clock controls time or continuous operation mode
- DC brushless motor, long service life and maintenance free
- Over speed detection and protection
- Free software ShakerPC, computer can control and document all operation values via RS232 interface
Rocking shaker
- Smooth see-saw rocking motion with fixed angle 9°
- Load up to 10kg
- Speed range of 10-70rpm
- DC brushless motor provides reliable and quiet running, maintenance free
- Designed for continuous or timed operation
- Digital speed control and LCD display, speed and timer can be viewed simultaneously
- Wide range of accessory platform to be used for variable size vessels, and non-slip mat holds vessels prevent slipping
3D shaker
- Gentle 3D motion with fixed angle 9°
- Load up to 5kg
- Speed range of 10-70rpm
- DC brushless motor provides reliable and quiet running, maintenance free
- Designed for continuous or timed operation
- LCD display for speed and timer adjustment. Speed and timer can be viewed simultaneously
- Wide range of accessory platform to be used for variable size vessels, and non-slip mat holds vessels prevent slipping
Model | SK-O330-Pro SK-L330-Pro | SK-O180-Pro SK-L180-Pro |
Power supply | 110/220V, 50/60Hz | |
Consumption | 30W | |
Shaking movement | Orbital /Linear | |
Orbital diameter [mm] | 10 | 4 |
Max. shaking weight (with attachment) [kg] | 7.5 | 2.5 |
Motor type | External rotor brushless motor | |
Motor rating input [W] | 28 | |
Motor rating output [W] | 15 | |
Speed range [rpm] | 100-500 (Orbital) | 100-800 (Orbital) |
100-350 (Linear) | 100-350 (Linear) | |
Speed display | LCD | |
Timer | Yes | |
Timer display | LCD | |
Time setting range [min] | 1-1199 | |
Run type | Timing / Continuous operation | |
Size [W*H*D mm] | 420*370*100 | 340*300*100 |
Weight [kg] | 13.5 | 8.1 |
Permissible ambient temp. | 5-40℃ | |
Permissible relative humidity | 80% | |
Protection class acc. DIN EN60529 | IP21 | |
RS232 interface | Yes | |
Model | SK-D3309-Pro | SK-R330-Pro |
Power supply | 110/220V, 50/60Hz | |
Power | 40W | |
Motor type | DC motor | |
Rocking motion | 3D orbital | See-saw rocking |
Tilt angle [o] | 9o | 9o |
Max. load capacity (with platform) [kg] | 5 | 10 |
Speed range [rpm] | 10-70 | |
Speed display | LCD | |
Timer | Yes | |
Timer display | LCD | |
Time setting range [min] | 1-1199 | |
Operation type | Continuous/ timed operation | |
Dimensions [D*W*H mm] | 430*360*106 | 410*360*200 |
Weight [kg] | 9 | |
Permissible ambient temperature [℃] | 5-40 | |
Permissible relative humidity | 80% | |
Protection class acc. To DIN EN60529 | IP21 | |
Mainly packed by Carton box or other common security package, you also can give us your special requirments about it. We will try our best to make sure the goods arrive safely.
At present, we are dealing on laboratory equipment and medical analytical instruments, such as
biological safety cabinet, laminar flow clean bench, fume hood, refrigerator and freezer, incubator, oven, autoclave, freeze dryer, spectrophotometer, centrifuge, Elisa reader and washer, Semi&Auto biochemistry analyzer, biochemistry reagents etc.
BIOBASE is a professional manufacturer of laboratory products from 1999. Our main products are Biosafety Cabinet (Class I/II/III), Laminar Flow Cabinet, Fume Hood, Biochemistry Analyzer, Reagent, Autoclave anf Incubator.
We have more than 800 employees and 2000 square meters production base, our output per year is amount to 10000 units. Pursuing the highst quality is the tenet if BIOBASE. We hope everybody will enjoy BIOBASE service to keep away from the infectious disease.
Our advantages:
-We built an excellent research team which consists of 50 professional engineers
-We have 14 years production experience and a strong technical production team, we adopt high-tech and state-of-the-art production equipments from Italy, Japan and Switzerland, tec.
-We have a strong quality control team to inspect all production stage, from the purchased accesory to the finished products.
-We have full sets of advanced quality assurance equipments
We have ISO9001 quality management system; ISO14001 environmental managemnet system, ISO13485, CE mark, MET and NAF49 certificate.
We got EN12469 certificate for Biosafety Cabinet in 2013.
Please contact me with the information below to get more details:
Contact: Ray Liu
