Re:Automatic Glassware Washer
Why should I use automatic glassware washer
1, Avoid to contact with the body of harmful substances directly, which is easy to cause damage for user;
2, Artificial cleaning effect is not reliable, which is easy to effect experimental results; The automatic glassware washer can realize the standardization of cleaning articles
3, Washing, disinfection, drying can be done in one machine, which is to replace artificial and reduce the labor cost, simplify work procedure.
Standard washing procedure
Pre-cleaning→washing with cleaner agent→rinse→ washing with neutralization agent→rinse→washing with hot water→drying
Product Features
(A)Perfect and efficient cleaning system
1, The high washing pressure (Configuration famouse brand circulation pump which is high temperature resistant, corrosion resistant
2, Perfect cleaning for glassware exterial surface (top and bottom are arranged rotary spray arm, the arms have many nozzles which is optimization arrangement to achieve cleaning all range angle
3, Perfect washing for vessel inner surface (cleaning column top nozzle and cylinder fan-shaped incision design, 360 ° cleaning vessel inner surface
4, Two peristaltic pumps achieve cleaner agent and neutralization agent adding automatically and accurately
5, the water temperature can be heated more than 93 °C, reach the middle level of disinfection(EN ISO 15883)
6, Set the self-cleaning program, regular cleaning for washing cabinet and pipeline.
(B)Convenient drying system
1, Independent air heater with circulating fan, improve the drying efficiency, the drying temperature can be set 50~90 °C
2, Using the HEPA air filter, to ensure the air cleanliness in the drying system, avoid air pollution
3, Hot air is through the nozzles of the top and bottom spray arms, the nozzles of cleaning column during drying procedure, ensure rapid drying of glassware inner and external surface.
(C)Professional design for structure
1, the machine adopts the high quality stainless steel material (SUS304 or SUS316); the washing pipeline adopts sanitary stainless steel pipe and valve which is corrosion resistance
2, The door adopts vacuum glass, sound insulation and noise reduction, which is convenient for the user to real-time observe the washing running.
3, Two water inlet interface design (tap water and pure water)
4, Drainage pipe water seal design, to prevent sewage counter-current
(D)The humanized design for control system
1, Human-computer interface using color LCD touch screen, reliable performance and convenient operation
2, the PLC control system, stable and reliable performance, no electromagnetic interference effects
3, Double temperature control for the water temperature and air temperature, ensure the cleaning, disinfection and drying temperature
4, Automatic fault diagnosis function, the screen display the fault information together with sound alarm.
(E)Intimate safety protection
1, The two points locking design, the door sealing more reliable, preventing water and steam overflow
2, Electronic security door lock, prevent the door accidental opening caused personal injury during cleaning and drying procedure
3, Equipment is with emergency switch, ensure the power can be cut off in case of emergency
4, Double protection for water temperature and air temperature, power shutdown protection in case of over temperature
5, Circulating pump high temperature protection, prevent the circulating pump damage in case of abnormal high temperature
6, The water cycle pipeline is with mesh filter, to prevent debris into the recycle, which is to protect the internal components
Specification:
Model | Dimension (W*D*H)mm | Voltage (V/Hz) | Power (KW) | Capacity (L) | Max Noise (dBa) | Water pressure(Mpa) |
BK-LW-120 | 980*740*830 | 220/50 | 6 | 120 | ≤50 | 0.3-0.8 |
BK-LW-220 | 710*680*1750 | 380/50 | 17 | 220 | ≤55 | 0.3-0.8 |
BK-LW-320 | 710*680*1900 | 380/5 | 19 | 320 | ≤55 | 0.3-0.8 |
BK-LW-420 | 1100*900*2000 | 380/50 | 22 | 420 | ≤60 | 0.3-0.8 |
Please contact me with the information below to get more details:
Contact: Ray Liu
